Weidmüller HDC 32B TOBU 1M40G 1221070000 Plug enclosure 1 pc(s)
EAN:
Part number:
Item no:
Product type
Plug enclosure
Thread size
M40
Case material
Aluminium, die cast
Type
HDC 32B TOBU 1M40G
Manufacturer part #
1221070000
Technical specifications
- EMC housing: No
- Number of cable input top: 1
- Number of cable input side: 0
- Type: Standard
- size: 10
- Bracket design: Transverse bracket
- suitable for ModulPlug®: Yes
- Upper part/lower part/cover: Upper part
- width Housing C: 82.5 mm
- Height Housing B: 79 mm
- Length Housing: 94 mm
- Tightening torque: 2 Nm
- Material Locking element: Stainless steel, stainless steel
- Type
HDC 32B TOBU 1M40G
- Product type
Plug enclosure
- Manufacturer part #
1221070000
- Features
+ transverse brace on the bottom part
+ thread
powder-painted
- Thread size
M40
- Type
Cable input top, connector housing
- Case material
Aluminium, die cast
- Factory colour
Grey
- Weight
394 g
- Content
1 pc(s)
- Width
98 mm
- Height
79 mm
- Length
94 mm
IP65
- Max. temperature
+125 °C
- Min. temperature
-40 °C
- UKCA
yes
