Weidmüller HDC HQP ALU 1003040000 Enclosure extension 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Enclosure extension
Case material
Plastic
Type
HDC HQP ALU
Series
RockStar® HDC HQP
Datasheet (PDF)
Highlights & Details
HDC enclosures, Size: HQ, Protection degree: IP 65, Bulkhead enclosure, Side-locking clamp on lower side, Standard
- HDC HQP ALU
Technical specifications
- Width of housing C: 28.8 mm
- Height of housing B: 19.5 mm
- Length of housing: 46.3 mm
- EMC housing: No
- Material of locking element: Stainless steel, stainless
- design: Standard
- size: HQ
- clamp design: Transverse bracket
- suitable for ModulPlug®: No
- upper part/lower part/cover: Lower part
- Mounting dimensions Width: 32.2 mm
- Mounting dimensions Height: 13.4 mm
- Hole spacing Length A2: 32.2 mm
- Seal: NBR
- flammability class according to UL 94: V-0
- Packaging type
Piece
- Type
HDC HQP ALU
- Product type
Enclosure extension
- Series
RockStar® HDC HQP
- Manufacturer part #
1003040000
- Features
+ transverse brace on the bottom part
- Case material
Plastic
- Factory colour
Grey
- Weight
27 g
- Content
1 pc(s)
- Width
35 mm
- Height
40.6 mm
- Length
67.1 mm
IP65
- Max. temperature
+125 °C
- Min. temperature
-40 °C
35
41 mm
67 mm
Beige
Double locking levers
FALSE
Plastic
-40-125 °C
V0
TRUE
Housing extension
IP65
Plastic
Other
Base unit
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 195466 Weidmüller HDC HQP ALU 1003040000 Enclosure extension 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 195466 Weidmüller HDC HQP ALU 1003040000 Enclosure extension 1 pc(s) Piece
Description
The special die-cast alloy and the multi-layered surface sealing provide complete protection for the HDC housings.
The cleverly designed interlock system is manufactured from stainless steel. This guarantees a long lifespan with high resistance to corrosion and impact.
The housing interlock system provides integrated safety. Our unique, patented spring system provides the housing interlock with a secure grip and prevents accidental opening.
The laser marking allows for easy and quick identification. Each housing is permanently labelled with a laser marking so that each product can be quickly designated and positioned.
Weidmüller RockStar® IP 65 / NEMA Type 4X housings - your first choice for industrial housings with IP 65 protection. The HQ version now offers particular protection - the bulkhead housing (cover and metal clamp) can be secured with a padlock.
The cleverly designed interlock system is manufactured from stainless steel. This guarantees a long lifespan with high resistance to corrosion and impact.
The housing interlock system provides integrated safety. Our unique, patented spring system provides the housing interlock with a secure grip and prevents accidental opening.
The laser marking allows for easy and quick identification. Each housing is permanently labelled with a laser marking so that each product can be quickly designated and positioned.
Weidmüller RockStar® IP 65 / NEMA Type 4X housings - your first choice for industrial housings with IP 65 protection. The HQ version now offers particular protection - the bulkhead housing (cover and metal clamp) can be secured with a padlock.
