Weidmüller HDC IP68 04A TOS 1M25G 1513390000 Plug enclosure 1 pc(s)
EAN:
Part number:
Item no:
Product type
Plug enclosure
Thread size
M25
Case material
Aluminium, die cast
Type
HDC IP68 04A TOS 1M25G
Manufacturer part #
1513390000
Technical specifications
- EMC housing: Yes
- Number of cable input at top: 1
- Number of lateral cable inputs: 0
- Design: Standard
- Size 1
- Clamp design: Screw cap
- Suitable for ModulPlug®: No.
- Upper part/lower part/cover: Upper part
- Length of housing: 50 mm
- Tightening torque: 2.2 Nm
- Material locking element: Stainless steel, stainless steel
- Type
HDC IP68 04A TOS 1M25G
- Product type
Plug enclosure
- Manufacturer part #
1513390000
- Features
+ thread
powder-painted
- Thread size
M25
- Case material
Aluminium, die cast
- Factory colour
Black
- Connection
Screw cap
- Weight
80 g
- Content
1 pc(s)
- Width
36 mm
- Height
60 mm
- Length
50 mm
IP68
IP69K
- Max. temperature
+125 °C
- Min. temperature
-50 °C
36
TRUE
60 mm
50 mm
Black
Screw
0
FALSE
TRUE
Aluminium
Powder coating
-50-125 °C
Other
Plug case
IP66
Aluminium
Other
Other
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2242655 Weidmüller HDC IP68 04A TOS 1M25G 1513390000 Plug enclosure 1 pc(s)
