Weidmüller KLIPPON K32 EX RAL7001 Universal enclosure 250 x 80 x 55 Aluminium Silver-grey 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Universal enclosure
Material
Aluminium
IP rating
IP66
IP67
Width
250 mm
Datasheet (PDF)
Technical specifications
- Mounting dimensions Width: 238 mm
- Mounting dimensions Height: 52 mm
- Operating temperature, max.: +135 °C
- Operating temperature, min.: -60 °C
- Lid fixing: M4 Torxedel steel screws with slit
- Sealing material: Silicone
- Torque Lid screws: 2.5 Nm
- Mounting mounting: Threaded holes M4
- Housing mounting: Holes 4 mm
- Material thickness: 4 mm
- Cover thickness: 2.5 mm
- Material thickness Housing: 4 mm
- Standards: IEC 60079-0, IEC 60079-7, IEC 60079-31
- Surface: Powder coated
- Packaging type
Piece
- Product type
Universal enclosure
- Features
Explosion-proof
- Material
Aluminium
IP66
IP67
- Factory colour
Silver-grey
- Width
250 mm
- Height
80 mm
- Dimensions
250 x 80 x 55 mm
- Weight
802 g
- Content
1 pc(s)
- Type
KLIPPON K32 EX RAL7001
- Dim
(W x H x D) 250 x 80 x 55 mm
- RoHS-compliant
Yes
- Manufacturer part #
1329690000
- Depth
55 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1952232 Weidmüller KLIPPON K32 EX RAL7001 Universal enclosure 250 x 80 x 55 Aluminium Silver-grey 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 1952232 Weidmüller KLIPPON K32 EX RAL7001 Universal enclosure 250 x 80 x 55 Aluminium Silver-grey 1 pc(s) Piece
