Name: Weidmüller MULTI-STRIPAX PV 1190490000 Electrician Cable stripping pliers Incl. cable cutter 2.5 up to 6 mm² Suitable fo
Brand: Weidmüller
SKU: 201298

A crimping pliers presses a contact onto a cable end. The pliers are black with orange handles.

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Stripping and cutting tool

MULTI-STRIPAX PV

Technical specifications

Height: 85 mm

Product type: Cable stripping pliers

Suitable for: Cables with non-standard coatings

Working area (cross section): 2.5 up to 6 mm²

Working area cross section (min.): 2.5 mm²

Operating range (cross section) (max.): 6 mm²

Range of use: Electrician

Length stop range: 2.3 up to 30 mm

Length stop (min.): 2.3 mm

Length stop (max.): 30 mm

Length: 40 mm

Suitable for: Weidmüller

Suited for model: 1190490000

Width: 250 mm

Weight: 548 g

Features: Incl. cable cutter

: TRUE

: 548 kg/m

: 250 m

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 201298 Weidmüller MULTI-STRIPAX PV 1190490000 Electrician Cable stripping pliers Incl. cable cutter 2.5 up to 6 mm² Suitable fo

User & Safety Instructions

User & Safety Instructions 201298 Weidmüller MULTI-STRIPAX PV 1190490000 Electrician Cable stripping pliers Incl. cable cutter 2.5 up to 6 mm² Suitable fo

Description

Stripping and cutting tool. Photovoltaic cables and comparable earthing and short-circuit proof lines, 6 mm². For fine-stranded and solid conductors with special insulation materials. High stripping quality for industrial application (according to request from the aviation). Conductor insulation stripping knife enable the special special form and the conductor structures. Stripping length with stop can be set. High flexibility by interchangeable stripping units. High repeatability of the stripping results. No damage to the conductor. High stability for long life and high reliability. Integrated cutting function.
