Weidmüller Pin housing PCB BL/SL Total number of pins 12 1615620000 50 pc(s)
EAN:
Part number:
Item no:
Product type
Pin housing PCB
Connector type
Plug, horizontal mount
No. of rows
1
Series
BL/SL
Total number of pins
12
Datasheet (PDF)
Highlights & Details
PCB connector
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 12
Our service for you
Technical specifications
- Product type
Pin housing PCB
- Connector type
Plug, horizontal mount
- No. of rows
1
- Connector system
wire-to-board
- Series
BL/SL
- Features
+ screw lock
- Pins per row
12
- Total number of pins
12
- Width
86 mm
- Content
50 pc(s)
- Dim
(L x W x H) 80 x 86 x 100 mm
- Manufacturer part #
1615620000
- Factory colour
Black
- Industrial packaging
Yes
- Contact material
Tin plated
- Height
100 mm
- Length
80 mm
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Type
SL 3.50/12/90F 4.5 SN BK BX
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 325025 Weidmüller Pin housing PCB BL/SL Total number of pins 12 1615620000 50 pc(s)
User & Safety Instructions
User & Safety Instructions 325025 Weidmüller Pin housing PCB BL/SL Total number of pins 12 1615620000 50 pc(s)
Description
PCB connector. Multi-pin connector, Flange, solder, 3.50 mm, number of poles: 12, 90°, solder pin length: 4.5 mm, tinned, black, Box.
This text is machine translated.
This text is machine translated.
