Weidmüller Pin housing PCB BL/SL Total number of pins 20 Contact spacing: 3.50 mm 1619410000 20 pc(s)
EAN:
Part number:
Item no:
Product type
Pin housing PCB
Connector type
Plug, horizontal mount
No. of rows
1
Series
BL/SL
CS
3.50 mm
Datasheet (PDF)
Highlights & Details
PCB connector
- Content: 20 pc(s)
- No. of rows: 1
- Total number of pins: 20
Technical specifications
- Product type
Pin housing PCB
- Connector type
Plug, horizontal mount
- No. of rows
1
- Connector system
wire-to-board
- Series
BL/SL
- CS
3.50 mm
- Pins per row
20
- Total number of pins
20
- Width
71.40 mm
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Content
20 pc(s)
- Dim
(L x W x H) 10.70 x 71.40 x 11.10 mm
- Connection
Print
- Case material
PBT
- Manufacturer part #
1619410000
- Factory colour
Orange
- Industrial packaging
Yes
- Contact material
Bronze, tin plated
- Nominal voltage
300 V
- Height
11.10 mm
- Length
10.70 mm
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Type
SL 3.50/20/90G 3.2SN OR BX
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 351552 Weidmüller Pin housing PCB BL/SL Total number of pins 20 Contact spacing: 3.50 mm 1619410000 20 pc(s)
User & Safety Instructions
User & Safety Instructions 351552 Weidmüller Pin housing PCB BL/SL Total number of pins 20 Contact spacing: 3.50 mm 1619410000 20 pc(s)
Description
PCB connector. Multi-pin connector on the side of closed, solder, 3.50 mm, number of poles: 20, 90°, solder pin length: 3.2 mm, tinned, orange, Box. 250 V (IEC) / 300 V (UL), 17 A (IEC) / 10 A (UL).
This text is machine translated.
This text is machine translated.
