Weidmüller Pin housing PCB SHL Total number of pins 4 1063250000 130 pc(s)
EAN:
Part number:
Item no:
Product type
Pin housing PCB
Connector type
Plug, mount
No. of rows
1
Series
SHL
Total number of pins
4
Datasheet (PDF)
Highlights & Details
PCB connector
- Content: 130 pc(s)
- No. of rows: 1
- Total number of pins: 4
Our service for you
Technical specifications
- Product type
Pin housing PCB
- Connector type
Plug, mount
- No. of rows
1
- Connector system
wire-to-board
- Series
SHL
- Pins per row
4
- Total number of pins
4
- Width
20.4 mm
- Content
130 pc(s)
- Dim
(L x W x H) 27.6 x 20.4 x 14.4 mm
- Connection
SMT
- Manufacturer part #
1063250000
- Industrial packaging
Yes
- Contact material
Copper alloy
- Board contact surface
Tin plated
- Connector contact surface
Tin plated
- Height
14.4 mm
- Length
27.6 mm
- RoHS-compliant
Yes
- Type
SHL-SMT 5.00/04GL 1.5RL
- UKCA
not relevant
