Weidmüller RCI484S15 Plug-in relay 115 V AC 8 A 2 change-overs 10 pc(s)
Product type
Plug-in relay
Coil nominal voltage
115 V AC
Control mode
monostable, 1 coil
Contact type
2 change-overs
Switching voltage (max.)
400 V AC
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
RCI relay, series 484
Our service for you
Technical specifications
- Product type
Plug-in relay
- Type
RCI484S15
- Coil nominal voltage
115 V AC
- Min. pick-up voltage
86.3 V AC
- Control mode
monostable, 1 coil
- Resistance (coil)
8100 Ω
- Contact type
2 change-overs
- Contact material
AgNi 90/10
- Switching voltage (max.)
400 V AC
- Switching current (max.)
8 A
- Max. switching capacity
2000 VA
192 W
- Creepage distance (coil/clips)
8 mm
- Connection
Jack connector
- Fall time
6 ms
- Durability
5 x 106 circuits
- Features
+ test button
- Min. temperature
-40 °C
- Max. temperature
+70 °C
- Weight
13.845 g
- Factory colour
Transparent
- Width
13 mm
- Height
29 mm
- Depth
26.7 mm
- Dim
(W x H x D) 13 x 29 x 26.7 mm
- Industrial packaging
Yes
- Content
10 pc(s)
- RoHS-compliant
Yes
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 391848 Weidmüller RCI484S15 Plug-in relay 115 V AC 8 A 2 change-overs 10 pc(s)
User & Safety Instructions
User & Safety Instructions 391848 Weidmüller RCI484S15 Plug-in relay 115 V AC 8 A 2 change-overs 10 pc(s)
Description
Relays. RIDERSERIES, number of contacts: 2, changer with Prufftaste, AgNi 90/10, nominal control voltage: 115V AC, Continuous current: 8 A, plug connection
