Weidmüller SAI-4-S 3P M8 L OL 1051760000 Sensor & actuator box (passive) M8 splitter + steel thread 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Sensor & actuator box (passive)
No. of signal spaces
4
No. of splitters
4-way
Type
SAI-4-S 3P M8 L OL
Datasheet (PDF)
Highlights & Details
Sensor/Actuator box
- SAI-AU M8 SB 8DO 2 A
Technical specifications
- Contact material: CuZn
- Insulation resistance: 109 Ω
- Connection thread: M8
- distribution outlet: With M12 outlet, 8-pin, A-coded
- Nominal voltage: 15 V - 30 V
- Towing chain suitability: No.
- Packaging type
Piece
- Product type
Sensor & actuator box (passive)
- No. of signal spaces
4
- Type
SAI-4-S 3P M8 L OL
- Trunk line
No
- No. of splitters
4-way
- Status indicator
No LED
- Connection
M8 socket
- Width
24 mm
- Length
113 mm
IP68
- Max. power rating per slot
2 A
- Total current (direct supply)
2 A
- Max. temperature
+70 °C
- Min. temperature
-20 °C
- Connector type (distribution boxes)
M8 receptacle
- Total no. of pins
3
- Weight
64 g
- Manufacturer part #
1051760000
- Factory colour
Grey
- Content
1 pc(s)
- Number of pins
3
- Height
18.2 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 195968 Weidmüller SAI-4-S 3P M8 L OL 1051760000 Sensor & actuator box (passive) M8 splitter + steel thread 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 195968 Weidmüller SAI-4-S 3P M8 L OL 1051760000 Sensor & actuator box (passive) M8 splitter + steel thread 1 pc(s) Piece
Description
Sensor/actuator passive splitter. SAI-passive. The new narrow M8 line from Weidmüller. This product family is distinguished by marking it at all slots. Even the 4-way distributor with 8-pin M12 has at all M8 slots a sufficiently large markers. Furthermore, this distributor shorter than many commercially available M8 types. Very narrow, short and Flat M8 distributor. The family is supplied with 4 up to 12 M8 slots, 3- or 4-pin. Even mixed populations of the M8 are at the customer's request. The M8 line is equipped with cross holes.
