Weidmüller Socket housing PCB RSV Total number of pins 18 Contact spacing: 5 mm 1444200000 25 pc(s)
EAN:
Part number:
Item no:
Product type
Socket housing PCB
Connector type
Plug, straight
No. of rows
1
Series
RSV
CS
5 mm
Datasheet (PDF)
Highlights & Details
PCB connector
- Content: 25 pc(s)
- No. of rows: 1
- Total number of pins: 18
Our service for you
Technical specifications
- Product type
Socket housing PCB
- Connector type
Plug, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
RSV
- CS
5 mm
- Pins per row
18
- Total number of pins
18
- Width
32.6 mm
- Pin Ø
0.97 mm
- Pin shape
Circular
- Nominal current
14 A
- Nominal current - rounded value
14 A
- Content
25 pc(s)
- Dim
(L x W x H) 12.7 x 32.6 x 17.5 mm
- Connection
Print
- Case material
Thermoplastic
- Manufacturer part #
1444200000
- Factory colour
Grey
- Industrial packaging
Yes
- Insulation material
Thermoplastic
- Contact material
Copper alloy
- Connector contact surface
Gold plated
- Nominal voltage
500 V
- Height
17.5 mm
- Length
12.7 mm
- RoHS-compliant
Yes
IP20 (when connected)
- Connector orientation
Perpendicular (to the PCB)
- Max. temperature
+100 °C
- Type
RSV1,6 LB18 GR 3,2 AU
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 321788 Weidmüller Socket housing PCB RSV Total number of pins 18 Contact spacing: 5 mm 1444200000 25 pc(s)
User & Safety Instructions
User & Safety Instructions 321788 Weidmüller Socket housing PCB RSV Total number of pins 18 Contact spacing: 5 mm 1444200000 25 pc(s)
Description
PCB connector. Female header, 5.00 mm, number of poles: 18, solder pin length: 3.2 mm, gold-plated, pebble gray, Box. Square connector with solder pin and lotbuchsenkontakte for PCB applications. High packing density by several rows and the use of crimp contacts in the counterpart. The connectors are encoded and with the counterpiece lockable. Supplied in a carton. 500 V (IEC) / 300 V (UL), 14 A (IEC) / 10 A (UL),.
