Weidmüller SSR 1132290000 1 A Switching voltage (max.): 275 V AC 20 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
10 V DC
Control voltage (max.)
32 V DC
Switching voltage (max.)
275 V AC
Current load (max.)
1 A
Datasheet (PDF)
Highlights & Details
Solid state relays
- Industrial packaging with 20 pieces
Technical specifications
- Storage temperature, max. 70 °C.
- Storage temperature, min.: -40 °C
- Status indicator: No.
- Switch-on delay: ≤ 10 ms
- Switch-off delay: ≤ 10 ms
- Voltage drop at max. load: ≤ 1 V.
- Leakage current < 1.5 mA
- Colour, black
- MTTF: 1,150 years
- On / off voltage 10 V / 8 V DC
- min Switching current 50 mA
- Protective circuit on load side: RC element
- Electrical strength, control side - load side: 2.5 kVeff
- Pitch in mm (P): 5 mm
- Product type
SSR
- Type
SSR 24VDC/MAX.240VAC 1A
- Connection
Connector
- Control voltage (min.)
10 V DC
- Control voltage (max.)
32 V DC
- Control voltage range
10 - 32 V DC
- Control current (max.)
13 mA
- Switching voltage (min.)
12 V AC
- Switching voltage (max.)
275 V AC
- Current load (max.)
1 A
- Contact type
1 maker
- Min. temperature
-20 °C
- Max. temperature
+60 °C
- Width
12.7 mm
- Height
29 mm
- Depth
15 mm
- Weight
5.2 g
- Industrial packaging
Yes
- RoHS-compliant
- Permanent current (max.)
1 A
- Content
20 pc(s)
Documents & Downloads
Datasheet
Datasheet 307027 Weidmüller SSR 1132290000 1 A Switching voltage (max.): 275 V AC 20 pc(s)
User & Safety Instructions
User & Safety Instructions 307027 Weidmüller SSR 1132290000 1 A Switching voltage (max.): 275 V AC 20 pc(s)
Description
Solid state relays.
