Weidmüller TRP 5VDC 1CO EMPTY Relay socket 5 V DC 10 A 1 change-over Piece 10 pc(s)
Packaging type
Piece
Product type
Relay socket
Contact type
1 change-over
Nominal voltage
5 V DC
Switching current (max.)
10 A
EAN:
Part number:
Item no:
Technical specifications
- Mounting rail: TS 35
- flammability class according to UL 94: V-0
- Overvoltage category: III
- Pollution degree: 2
- surge voltage: 6 kV (1.2/50 µs)
- Stripping length Rated connection: 8 mm
- clamping range, rated connection: 1.5 mm²
- clamp range, min.: 0.14 mm²
- clamp range, max.: 2.5 mm²
- conductor cross-section AWG, min.: 26
- conductor cross-section AWG, max.: 14
- conductor cross-section, single wire, min. mm² 2.5 mm²
- Conductor cross-section, fine-wired, min.: 0.14 mm²
- Conductor cross-section, fine-wired, max.: 2.5 mm²
- Blade dimensions: 0.4 x 2.0 mm
- Packaging type
Piece
- Product type
Relay socket
- Type
TRP 5VDC 1CO EMPTY
- Connection
Push-in button
- Factory colour
Black
- Contact type
1 change-over
- Nominal voltage
5 V DC
- Switching current (max.)
10 A
- Features
+ LED display
IP20
- Max. temperature
+60 °C
- Min. temperature
-40 °C
- Depth
87.8 mm
- Width
6.4 mm
- Height
89.6 mm
- Dim
(W x H x D) 6.4 x 89.6 x 87.8 mm
- Content
10 pc(s)
- Weight
24 g
- UKCA
not relevant
