Name: Weidmüller UR20-8DI-P-3W-HD 1315190000 PLC input module 24 V DC
Brand: Weidmüller
SKU: 1889329

Technical specifications

Mounting dimensions Height: 128 mm
Operating temperature, max.: 60 °C
Operating temperature, min.: -20 °C
Storage temperature: -40 °C ... +85 °C
flammability class according to UL 94: V-0
Test voltage: 500 V
shock: 15 g over 11 ms, half sine wave, according to IEC 60068-2-27
Pollution degree: 2
Vibration resistance: 5 Hz ≤ f ≤ 8.4 Hz: 3.5 mm amplitude acc. To IEC 60068-2-6, 8.4 Hz ≤ f ≤ 150 Hz: 1 g acceleration according to IEC 60068-2-6
Overvoltage category: II
Connection type: Push IN
conductor cross-section, single-wire, max.: 0.35 mm²
conductor cross-section, single-wire, max. (AWG): AWG 22
conductor cross-section, single-wire, min.: 0.14 mm²
conductor cross-section, single-wire, min. (AWG): AWG 26
conductor cross-section, fine-wired, max.: 0.35 mm²
conductor cross-section, fine-wired, max. (AWG): AWG 22
conductor cross-section, fine-wired, min.: 0.14 mm²
conductor cross-section, fine-wired, min. (AWG): AWG 26
Single-channel diagnostics: No
Module diagnostics: Yes
Input filter: Configurable
Input voltage High:> 11 V
Input voltage Low:< 5 V
Sensor connection: 2-conductor, 3-conductor
Sensor supply: Yes
Fieldbus protocol: CANopen, DeviceNet, EtherCAT, Ethernet/IP, Modbus/TCP, PROFINET IRT, PROFIBUS DP-V1, POWERLINK
Galvanic separation: DC 500 V between current paths
Module type: Digital input module
Interface: U-remote system bus
possible conductor technology: 3 conductors, 1 conductor, 2 conductors
transfer rate system bus, max.: 48 Mbit
power consumption from IIN (power segment of the fieldbus coupler), type.: 8 mA
