Wieland Electric 92.050.9153.0 Ribbon cable adapter
EAN:
Part number:
Item no:
Number
Total (€ 39.49 / piece)
€ 39.49
plus VAT.
Technical specifications
- Product type
Ribbon cable adapter
- Type A
Terminals
- Connection
IDC
- Rated voltage
400 V
- Test current
32 A
- Cable Ø (max.)
18 mm
- Cable Ø up to
9.7 mm
- Cable Ø range
9.7 - 18 mm
- Number of pins
5
IP20
- System
gesis® NRG
50 mm
Branch
TRUE
51.5 mm
Integrated in plug-in connector
32 A
400 V
5
138.4 mm
Polyamide (PA)
9.7-18 mm
TRUE
IP20
3, N, PE, 2, 1
0.01 kWh
Screw connection
2.5-6 mm²
2.5-6 mm²
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3282619 Wieland Electric 92.050.9153.0 Ribbon cable adapter
Description
Gesis® NRG flat cable adapter 690 V
32A
For tapping the 5G10 mm² flat cable using IDC
Connecting round cables: 2.5 ... 6 mm² by means of screw connection.
This text is machine translated.
32A
For tapping the 5G10 mm² flat cable using IDC
Connecting round cables: 2.5 ... 6 mm² by means of screw connection.
