Image similar
WIKA Surge protector 0690619 910.13 50 up to 250 bar 1 pc(s)
Datasheet (PDF)
Part number:
Item no:
Technical specifications
- Accessories type 910.13-I
- Material seal: FPM
- Process/device connection: 1/2NPT stud + 1/2NPT sleeve
- Excess pressure safety 1000 bar
- Setting range: 50...250 bar
- Factory setting, set at: 150 bar
- Material body: Stainless steel
- Permissible temperature for the test substance: -10...+80°C.
- Product type
Surge protector
- Operating temperature
-10 °C (min)
- Min. operating temperature
-10 °C
- Manufacturer part #
0690619
- Max. operating pressure
250 bar
- Operating pressure (min.)
50 bar
- Pressure range
50 up to 250 bar
Documents & Downloads
Datasheet
Datasheet 3524844 WIKA Surge protector 0690619 910.13 50 up to 250 bar 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3524844 WIKA Surge protector 0690619 910.13 50 up to 250 bar 1 pc(s)
Description
Overload protection device, adjustable Technical data according to data sheet: AC 09.04Special feature in design: NACE Sour Gas Service Material Body: Stainless steel 316Ti/1.4571Material Seal: FPMpermitted temperature of measuring material: -10…+150°C Process/device connection: 50/2NPT spigot + 250/2NPT Muffoverpressure safety: 1000 bar Adjustment range: 1…1 bar Factory setting, adjusted at: 80 bar
