Yealink Meetingboard 75 Pro-A02 Conferencing system
EAN:
Part number:
Item no:
Highlights & Details
Yealink MeetingBoard 75 Pro/MB75Pro-A02
- Touch screen 190.5 cm (75")
- 3840 x 2160 pixel
- 400 cd/m² 1200:1 60 Hz
- In-built loudspeaker In-built microphone
- Bluetooth 5.1 Ethernet/LAN
- VESA-bracket 800 x 600 mm
- 277 W
Technical specifications
- Contrast ratio: 1200:1
- Installed operating system: Android™
- WLAN standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
- Product type
Conferencing system
- Bluetooth
5.1
- Bluetooth
Yes
- Depth
105 mm
- Height
1081 mm
- Width
1705 mm
- Screen size diagonal (inches)
75 inch
- Display resolution
3840 x 2160 Pixel
- Frame rate
60 Hz
- No. of HDMI ports
2 x
- Processor cores (No.)
8 x
- Touchscreen (display)
Yes
- Memory capacity
8 GB
- Microphone
Yes
- Brightness
400 cd/m²
800 x 600 mm
- Weight
52.2 kg
- Wi-Fi
Yes
- Operating temperature (T-T)
0 - 40 °C
- Number of simultaneous touchpoints
20
- Ethernet LAN
yes
- VESA mounting
yes
- Built-in speaker(s)
yes
- HDMI output ports quantity
1
- Operating relative humidity (H-H)
5 - 95 %
- Storage temperature (T-T)
-20 - 60 °C
- Package weight
65 kg
- Built-in processor
yes
- Built-in camera
yes
- Power consumption (max)
277 W
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3843868 Yealink Meetingboard 75 Pro-A02 Conferencing system
Description
The MeetingBoard Pro combines video conferencing, display and intelligent whiteboarding in an elegant all-in-one solution with plug and play convenience and a clean design. With Pro View, Pro Sound powered by Pro Core, it offers a triple 50 MP camera system with advanced AI for precise tracking and a 16 MEMS microphone array with AI-supported audio for crystal-clear calls up to 12 meters away. MeetingBoard Pro supports Android or Windows solutions. Based on Android 13 with MEP security and compatible with teams, Zoom and BYOD, it is the ultimate meeting solution, expandable with plug and play accessories such as 12x pro PTZ cameras and extension microphones.
This text is machine translated.
This text is machine translated.
Features
- High quality display
- With a screen size of 75 inches and a resolution of 3840 x 2160, the display of the Yealink MeetingBoard 75 Pro offers a clear and lively picture quality, so that every detail is visible.
- Extraordinary audio performance
- Equipped with 4 speakers and 16 microphones as well as technologies such as beamforming and noise suppression, this meeting board ensures that each voice is played back clearly and each sound is reproduced precisely.
- Versatile connectivity options
- The device supports a range of ports, including HDMI, USB and Ethernet, making it easy to integrate with different hardware and operate with different software applications.
- Interactive features
- With its integrated interactive whiteboard and multi-touch technology, the Meeting Board transforms joint sessions into dynamic experiences, making brainstorming and sharing ideas easier.
- Economical design
- The Yealink MeetingBoard 75 Pro is ENERGY STAR-certified and ensures a reduced power consumption without loss of performance, WAS makes it a future-proof choice for business use.
Scope of delivery
- Yealink meeting board 75 pro
- CAT5E network cables - 3 m
- 4 pins, 3 cable ties
