3M 7000092184 93-AP 621-1 Cold shrink connector set Content: 1 pc(s)
Product type
Cold shrink connector set
Min. cross section
95 mm²
max. cross section
300 mm²
Content
1 pc(s)
Manufacturer part #
7000092184
EAN:
Part number:
Item no:
Technical specifications
- Number of conductors: 1
- Design: Cold shrink
- Rated voltage U0/U (um): 12/20 (24) kV
- With concentric shielding: Yes
- For connecting paper cables with plastic-insulated cables: no.
- Product type
Cold shrink connector set
- Min. cross section
95 mm²
- max. cross section
300 mm²
- Content
1 pc(s)
- Manufacturer part #
7000092184
- Type
93-AP 621-1
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2297869 3M 7000092184 93-AP 621-1 Cold shrink connector set Content: 1 pc(s)
Description
The 3M 3M cold shrink connection set is factory tested and designed for the unique cold shrink installation system. The products are delivered pre-stretched on a removable support spiral and thus enable an efficient and simple installation. The electrical field control and Faraday cage, both integrated into the insulation body, simplify the installation. Due to the specific properties of the insulating silicone body, a large number of terminations are possible on cable cross-sections. 3M 3M cold shrink fittings for medium voltage have been developed as a simple and safe solution for the connection of medium voltage cables.
