ALPS 192494 Studio fader 10 kΩ Mono 0.5 W linear 1 pc(s)
EAN:
Part number:
Item no:
Product type
Studio fader
Resistance
10 kΩ
Resistance characteristic
linear
Movement (±1)
100 mm
Output
Mono
Datasheet (PDF)
Number
Total (€ 29.99 / piece)
€ 29.99
incl. VAT
14-day return policy included
Highlights & Details
Studio fader
- RoHS compliant
Technical specifications
- Synchronism better 2 dB at centre position
- Slider travel 100 mm
- Insertion loss< 0.1 dB
- Attenuation 100 dB max.
- Mounting 1.2 x 8 mm
- Mounting hole distance: 120 mm
- Service life 100,000 slide cycles min.
- Product type
Studio fader
- Resistance
10 kΩ
- Resistance characteristic
linear
- Movement (±1)
100 mm
- Output
Mono
- Power rating
0.5 W
- Tolerance ±
0.2 %
- Content
1 pc(s)
- Type
192494
- Type
D cell
- Adjustment range
Mounting 1.2 x 8 mm
- Tolerance
± 20 %
- Type
RSAOK11 mono 10K linear
Documents & Downloads
Datasheet
Datasheet 442844 ALPS 192494 Studio fader 10 kΩ Mono 0.5 W linear 1 pc(s)
User & Safety Instructions
User & Safety Instructions 442844 ALPS 192494 Studio fader 10 kΩ Mono 0.5 W linear 1 pc(s)
Description
Professional studio fader for high-end audio equipment and studio mixing desks. These potentiometers are distinguished by their extremely smooth, jerk-free movement.
Scope of delivery
- Supplied without slider button.
