Name: Arduino UNO™ Q VLM-Bundle USB Arduino UNO Q 4 GB 4 x 2.0 GHz Camera card, PSU, USB cable
Brand: Arduino
SKU: 3833386

Raspberry Pi-compatible camera kit with USB webcam, single-board computer, cable, adapter, and international power plugs on a white background.

A black HD webcam with a mount and lens in the centre, used for video calls or recordings.

'A compact Arduino circuit board featuring various components and a USB-C port, designed for electronic prototyping and development.'

'An Arduino Uno Q microcontroller partially emerging from its box, featuring a circuit board with various components and connectors.'

Arduino UNO Q board with Qualcomm chip, USB-C port, and multiple I/O pins, designed for IoT applications and software development.

A microcontroller board with various electronic components, labeled 'Arduino UNO R4', featuring a Qualcomm chip and connection ports.

Black USB-C hub/dongle with multiple ports, including USB-A, HDMI, Ethernet, and an SD card slot, connected by a short cable.<br>

Black square wall charger with interchangeable plug adapters and retail packaging shown on a white background.

'ARDUINO USB-C CABLE' box with a black braided USB-C cable extending out.

1/9

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Arduino® UNO™ Q (4 GB / 32 GB eMMC) VLM-Bundle with Logitech C920 Webcam with USB-connection

Complete Edge-AI ecosystem: Direct entry into image processing without additional system components.
Flexible positioning: Thanks to the integrated mounting clips of the Logitech C920, the camera can be mounted variably on the measuring stand or prototype structure.
Non-disruptive operation: The 9A power supply ensures stable operation even at maximum processor and peripheral utilization.

Technical specifications

Microprocessor (MPU): Qualcomm Dragonwing™ QRB2210: Quad-Core Arm® Cortex®-A53 with 2.0 GHz / Adreno GPU 3D graphics accelerator: 2x ISP (13 MP + 13 MP or 25 MP) with 30 fps
Microcontroller (MCU): STM32U585 / Arm® Cortex®-M33 with up to 160 MHz / 2 MB flash memory / 786 KB SRAM
Power supply: Via USB-C port 5 VDC max. at 3 A / input voltage (VIN): 5 VDC
USB 1× USB-C connection with host/device roller switching, current roller circuit and video output
Connectivity: Wi-Fi® 5 2,4/5 GHz with integrated antenna / Bluetooth® 5.1 with integrated antenna
INTERFACES I2C/I3C, SPI, PWM, CAN, UART, PSSI, GPIO, JTAG, ADC
Video: Video output support via USB-C, MIPI DSI pins on the JMEDIA header
4× RGB LEDs, user-controlled / 8x13 blue LED matrix / 1x QWIIC connector, 3V3 voltage, I2C / 1x user pushbutton / JCTL: MPU remote debug connection
Audio: Microphone input / headphone output / line output on JMISC
Dimensions: 68.85 mm x 53.34 mm (UNO form factor)
MPU Operating System: Linux Debian OS with upstream support
Real-time operating system: Arduino Core on Zephyr OS
Containment: Docker- und Docker Compose-support
Supported operating systems for Arduino APP Lab: Windows: Windows: 10 or higher (64-bit) / MacOS: MacOS 11 or higher (64-bit) / Linux: Ubuntu 22.04 or higher and Debian Trixie (64-bit)

Product type: SBC starter kit

Type: Arduino UNO Q

Processor: ARM Cortex-A53

Processor cores (No.): 4 x

: 4 GB

Clock speed: 2.0 GHz

Operating system (Version): Linux

Memory capacity: 32 GB

Bluetooth: 5.1

Power supply (LOV): via USB
via PSU (optional)

Content: Camera card
PSU
USB cable

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3833386 Arduino UNO™ Q VLM-Bundle USB Arduino UNO Q 4 GB 4 x 2.0 GHz Camera card, PSU, USB cable

Description

The Arduino UNO Q VLM USB webcam bundle provides a complete hardware basis for the development and evaluation of local edge AI and Vision language model applications (VLM). Component coordination ensures a reliable power supply and flexible image acquisition via a standardized USB interface.

Target groups & application areas
Ideal for developers, industrial prototyping, research institutions and system integrators who want to test and use visual AI models with plug-and-play USB peripherals.
