AS Schwabe Optiline 46670 LED outdoor floodlight (+ motion detector) EEC: E (A - G) LED (monochrome) 30 W Black
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
AS Schwabe Optiline LED spotlight with 30 Watt motion detector
- 15 cm rubber sheathed cable H07RN-F 3G1.5 with fast connection adapter (230 V, 16 A)
- For connection of cross-section cables 3G2.5
- Motion detector adjustable 10s - 10min, 3 - 1000Lux, 4-10m
- Power: 30W / luminous flux: 3600 lm / 120 lm/W.
Technical specifications
- 40,000 H service life
- Beam angle: 120°
- 15 cm cable with quick connection adapter
- Product type
LED outdoor floodlight (+ motion detector)
- Type
Rectangular
- Operating voltage
230 V
- Bulb type
LED (monochrome)
LED
- Rating per bulb
30 W
30 W
4000 K
- Colour
Neutral white
3600 lm
- Total luminous flux
3600 lm
- Coverage max. (width)
10 m
- Adjustable on-time (min.)
10 s
- Adjustable on-time (max.)
10 min
- Protection class
I
IP44
- Factory colour
Black
- Material
Plastic
E (A - G)
- Light bulb included
Yes
- Cable length
15 cm
- Cable type
H07RN-F
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3645945 AS Schwabe Optiline 46670 LED outdoor floodlight (+ motion detector) EEC: E (A - G) LED (monochrome) 30 W Black
User & Safety Instructions
User & Safety Instructions 3645945 AS Schwabe Optiline 46670 LED outdoor floodlight (+ motion detector) EEC: E (A - G) LED (monochrome) 30 W Black
Description
Powerful LED spotlight with motion detector and satin finish diffuser. With 30 watt it delivers approx. 3600 lumens (neutral white, 4000 K). Robust plastic casing with aluminum cooling plate, IP44-protected. Integrated Quick connection adapter, adjustable motion sensor (10 s-10 min / 3–10000 Lux / 4–10 m), replaceable LED board. Ideal for outdoor use
This text is machine translated.
This text is machine translated.
Features
- Extremely long-lasting LEDs: Life over 40000 hours (120 lm/W)
- Plastic housing with heat sink made from aluminum
- With pressure compensating element to avoid condensation and corrosion (from 50 watts)
- Satin finish disc
- Motion detector adjustable 10s - 10min, 3 - 1000Lux, 4 - 10m
- Colour reproduction: CRI >80
- Angle of radiation 120°
- With fast connection adapter, connectable wire cross-section 3G2,5
- Connection 230 V/16 A.
- Replaceable LED board
- Protection class I
- IP44: Foreign body and splash-proof
Scope of delivery
- Optiline LED spotlight 30W with motion detector
