ATEN CS22U-AT 2 ports KVM changeover switch VGA USB 2048 x 1536 Pixel

EAN:
Part number:
Item no:
A KVM switch with four VGA and USB cables, used for connecting multiple computers to a single monitor or keyboard.
A black ATEN 2-Port USB KVM switch with cables. Two USB and one VGA port are visible. Model number: CS22U.
Diagram shows KVM switch connection: 'Console' to PC (Win) or Server (Mac, Sun, Linux) via 'CS22U' with remote control switch.
Black and navy blue foot switch with a round button and cable, for operating devices by foot pressure.
1/4
Datasheet (PDF)
Fast track dispatch on Tue 27 Oct
45 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 26.99 / piece)
€ 26.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Aten CS22U KVM switch

  • A USB console controls two USB Computer
  • Highest resolution up to 2048 x 1536 pixels
  • No external power supply required

Technical specifications

Product type

KVM changeover switch

No. of switchable PCs

2

Video via

VGA

Video resolution

2048 x 1536 Pixel

Controller

USB

Audio headphones

No

Audio microphone

No

No. of USB 2.0 ports

2 x

Stackable

No

Rack mount option

No

Switch function

Hot key

Key

Power supply (LOV)

not required

Factory colour

Black

Weight

0.3 kg

Length

25 mm

Width

82 mm

Height

70 mm

Port

2 ports

Dim

(L x W x H) 25 x 82 x 70 mm

Depth

70 mm

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 989227 ATEN CS22U-AT 2 ports KVM changeover switch VGA USB 2048 x 1536 Pixel

User & Safety Instructions

User & Safety Instructions 989227 ATEN CS22U-AT 2 ports KVM changeover switch VGA USB 2048 x 1536 Pixel

Description

Features.
- One USB console controls two USB computers- Supports multifunction mice- Multiplatform support - Windows, Mac, Linux and Sun- USB mouse port can be used for USB 1. 1 hub ad USB 1. 1 peripheral sharing- Superior video quality - up to 2048 x 1536; DDC2B- Non-poweredPackage Contents.
- 1x CS22U 2-Port USB Cable KVM Switch with Remote Port Selector- 1x User Instructions

Features

  • Supports Multi-function mice
  • Multi-platform compatible with Windows, Mac, Linux, and sun.

Scope of delivery

  • CS22 U USB KVM switch with 2 Ports
  • User manual
