ATEN VC880 HDMI™ Extension via data cable 15 m
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Aten AT-VC880
- Reinforced the HDMI input signal for transmission paths of up to a maximum of 15 m
- Resolutions up to 1920 x 1080 (1080p)
- Extracts the HDMI signal and makes it available as a separate sound source
Technical specifications
- Product type
Extension
- Transfer type
via data cable
- Interfaces (input)
HDMI™
- Interfaces (output)
HDMI™
- Resolution (max.)
1920 x 1080 p
- Range (max.)
15 m
- Factory colour
Black
- Weight
460 g
- Length
200 mm
- Width
82 mm
- Height
25 mm
- Dim
(L x W x H) 200 x 82 x 25 mm
- Type A
HDMI plug
- Type B
HDMI plug
- Type
Amplifier
- Connection type
HDMI
Variants(All information is without VAT, plus shipping costs)
Resolution (max.)
Interfaces (input)
Range (max.)
Interfaces (output)
1920 x 1080 p
HDMI™
15 m
HDMI™
Minimum order quantity: 1
Multiple: 1
€ 92.43*
ATEN CE600 DVI, USB A (USB 2.0) Extension via RJ45 network cable 60 m
1920 x 1200 p
DVI
60 m
DVI
Minimum order quantity: 1
Multiple: 1
€ 259.66*
ATEN CE700A VGA, USB A (USB 2.0) Extension via RJ45 network cable 150 m
1920 x 1200 p
VGA
150 m
VGA
Minimum order quantity: 1
Multiple: 1
€ 134.45*
ATEN UCE60 USB A (USB 1.1) Extension via RJ45 network cable 60 m
USB A (USB 1.1)
60 m
USB A (USB 1.1)
Minimum order quantity: 1
Multiple: 1
€ 39.49*
ATEN VE066-AT DVI Extension via RJ45 network cable 20 m
1920 x 1080 p
DVI
20 m
DVI
Minimum order quantity: 1
Multiple: 1
€ 14.28*
ATEN VE150A-AT-G VGA Extension via RJ45 network cable 150 m
1280 x 1024 p
VGA
150 m
VGA
Minimum order quantity: 1
Multiple: 1
€ 92.43*
Documents & Downloads
Datasheet
Datasheet 989244 ATEN VC880 HDMI™ Extension via data cable 15 m
User & Safety Instructions
User & Safety Instructions 989244 ATEN VC880 HDMI™ Extension via data cable 15 m
Description
Features.
- Repeats HDMI input signal up to 15 meters- Extracts HDMI audio signal and outputs as additional audio source- Supports optical / coaxial digital audio and analog stereo audio*- HDCP 1. 1 compatible- Superior Video Quality – up to 1920x1080 (1080p)- Firmware upgradable- CH2/CH5. 1/Auto mode audio channel selection- HDMI (3D)- Supports Audio on/off switch for HDMI output- Expandable to three levels – provides three levels of audio output for one HDMI at distance up to 45 mPackage Contents.
- 1x VC880 HDMI Repeater Plus Audio De-embedder- 1x 0AD6-1605-09EG Power Adapter- 1x User Instructions
- Repeats HDMI input signal up to 15 meters- Extracts HDMI audio signal and outputs as additional audio source- Supports optical / coaxial digital audio and analog stereo audio*- HDCP 1. 1 compatible- Superior Video Quality – up to 1920x1080 (1080p)- Firmware upgradable- CH2/CH5. 1/Auto mode audio channel selection- HDMI (3D)- Supports Audio on/off switch for HDMI output- Expandable to three levels – provides three levels of audio output for one HDMI at distance up to 45 mPackage Contents.
- 1x VC880 HDMI Repeater Plus Audio De-embedder- 1x 0AD6-1605-09EG Power Adapter- 1x User Instructions
Features
- On/Off switch for sound output of the HDMI signal
- Digital Sound output via fiber or coaxial connection as well as analogue stereo sound output
- HDCP 1.1 compatible
- Firmware update possible
- Tonkanalauswahl for 2-channel, 5.1-channel or automatically
- HDMI (3D).
- On/Off switch for sound output of the HDMI signal
- Series connection to a maximum of three levels - enables the sound on three levels for a HDMI signal for distances up to 45 m
Scope of delivery
- HDMI repeater
- Power supply unit
- User manual.
