Auxiliary contactor 2.5 mm² 1 change-over Schneider Electric M9A26914

This electrical accessory from Acti9 is a changeover contact (NORMALLY OPEN contact/NORMALLY CLOSED contact) for displaying the position OPEN or CLOSED of the circuit breaker. Operating current is between 2mA and 100mA at a frequency of 50Hz to 60Hz at 24VAC to 240VAC & 24VDC to 220VDC. Open / closed, auxiliary contact. It has 1 position switches with contacts of type 1 changeover contact. Intended for industrial and OEM installations. This electrical accessory is compatible with the Multi9 series such as C60BP, C60SP, C60 and N40. The OF is used for either the device short name or compatibility code. Screw terminal connection at the lower side. The connection enables rigid copper cables with a cable cross-section of 2.5 mm². Screw terminal connection on the underside. The connection permits flexible copper cables. The cable cross-section of 2 cables allows a cable cross-section of 1.5 mm². Screw terminal connection on the underside. The connection permits rigid copper cables. The cable cross-section of 2 cables allows a cable cross-section of 2.5 mm². The UI rated insulation voltage is up to 500 V. The rated surge voltage Uimp is 4kV. It can be mounted on a DIN rail for modular installation. The width in the 9 mm grid is 1. The dimensions are (W) 9mm x (H) 85mm x (D) 68mm. The color of the product is white. The product weight is 29 g. The degree of contamination is 3. The tropicalization level is Treatment 2. The stripping length is 9 mm. The tightening torque for the connection is 1N.m (bottom) for the screwdriver type PZ1. The IP protection class is IP20. The operating temperature is between -25°C and +70°C. The storage temperature ranges from -40°C to +85°C. This product complies with the standards EN/IEC 60947-5-1, EN/IEC 60947-5-4, GB/T 14048.5, GB/T 14048.17, UL 1077. UL 489, CSA C22.2 No. 0-10, CSA C22.2 No. 5-13, CSA C22.2 No. 235-04 and CSA C22.2 No. 65-03. It has EAC and CCC quality labels and is certified with CE, UKCA, UL and CSA certificates.

This text is machine translated.
