Image similar
Bachmann 692.180 Current Cable Black 2.00 m
EAN:
Part number:
Item no:
Technical specifications
- Temperature range laid fixed: -40°C to +70°C
- Temperature range, moving: -50°C to +70°C
- Outer diameter: 8 mm
- Spiral length min.: 0.5 m
- Spiral length max.: 2.0 m
- Cable type: CS-YMH11Y-J-3x 1.5 mm²
- Product type
Current Cable
- Cable use
Current
- Version
Cable
- Cable features
Spiral cable
- Cable length
2.00 m
- Factory colour
Black
- Nominal voltage (details)
500 V
- Cable type
CS-YMH11Y-J 3x 1.5mm²
- Cross section (each core)
1.5 mm²
- Insulation material
PUR
- Connection type
DC (current)
- Nominal voltage
500 V
- Outside Ø
8 mm
- Nominal voltage U0
230 V
- Spiral lenght (max.)
2000 mm
- Spiral length (min.)
500 mm
- Max. temperature range (fixed installation)
+70 °C
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (flexible installation)
+70 °C
- Min. temperature range (flexible installation)
-50 °C
- No. of leads
3 x
- Core layout
Class 5, stranded
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1838622 Bachmann 692.180 Current Cable Black 2.00 m
Description
Bachmann 692.180. Cable length: 2.5 m, cable color: black
