Highlights & Details
Non-contact phase and magnetic field tester
- Integrated test magnet for functional testing
- Magnetic field test via green LED probe tip (magnet activated)
- High sensitivity for 12 V voltage range can be switched on via button
- Testing of permanent, dc and AC-reduced magnetic fields
Technical specifications
- Power supply: 2x AAA battery
- Product type
Non-contact voltage tester
- Reading type
Phase
- Display
Acoustic
LED
- V AC reading range
200 up to 1000 V
- V DC reading range
12 up to 1000 V
- Reading category
CAT III 1000 V
CAT IV 600 V
Manufacturer's standards (no certificate)
- Dim
(L x W x H) 153 x 20 x 25 mm
- Weight
40 g
- Max. frequency
65 Hz
- Min. frequency
45 Hz
- Frequency range
45 Hz - 65 Hz
- V AC reading range (max.)
1000 V
- V AC reading range (min.)
200 V
- Voltage DC reading range (max.)
1000 V
- Voltage reading range DC (min.)
12 V
- Width
20 mm
- Height
25 mm
- Length
153 mm
- Type
VT 2
- Factory colour
Multicolour
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2299188 Benning VT 2 Non-contact voltage tester CAT III 1000 V, CAT IV 600 V Acoustic, LED
Description
· Automatic switch-off
· Shock-proof and break-proof ABS housing
· Capacitive measurement method does not require any current flow
· Battery compartment can be easily opened via robust screw cap · Contact-free testing, no contact to the electrical conductor required · Flashing frequency of the LED probe tip and signal tone frequency rising to
the voltage level
This text is machine translated.
Scope of delivery
- Incl. 2 x 1.5 V Micro/ AAA/ LR03 battery
- Pen clip
