Name: Boxexpert Treva grau 250200150 Wall-mount enclosure 200 x 250 x 150 x 150 Steel plate Light grey 1 pc(s) Piece
Brand: Boxexpert
SKU: 3404545

A rectangular grey metal enclosure with rounded edges and four visible screws at the corners.

Packaging type

Piece

Product type

Wall-mount enclosure

Material

Steel plate

IP rating

IP66

Width

250 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Colour RAL 7035
Coating: Polyester paint coating
Material: Cover / door: Steel plate
Material: Lower part: Steel sheet
5 mm double bit lock, 1-point lock
Resistance: Alkaline, oils, salts, etc.
Cover - transparent: No.
Inner dimensions (mm): 204 x 154 x 129
UL approval: No.
Impact strength: IK10

Packaging type: Piece

Product type: Wall-mount enclosure

Features: wallmount option

Material: Steel plate

: IP66

Factory colour: Light grey

Length: 200 mm

Width: 250 mm

Height: 150 mm

Dimensions: 200 x 250 x 150 mm

Weight: 3.45 kg

Content: 1 pc(s)

Type: Treva grau 250200150

Dim: (L x W x H) 200 x 250 x 150 mm

RoHS-compliant: Yes

Manufacturer part #: BXPIMB252015-T01

Depth: 150 mm

Halogen-free: Yes

Max. ambient temperature: 60 °C

Min. ambient temperature: -25 °C

Documents & Downloads

Datasheet

Datasheet 3404545 Boxexpert Treva grau 250200150 Wall-mount enclosure 200 x 250 x 150 x 150 Steel plate Light grey 1 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 3404545 Boxexpert Treva grau 250200150 Wall-mount enclosure 200 x 250 x 150 x 150 Steel plate Light grey 1 pc(s) Piece

Description

Behind the Treva series from BOXEXPERT is a high-quality and at the same time cost-effective wall cabinet made of steel sheet. The case is perfectly suitable for outdoor use thanks to the hardened polyester paint coating with UV protection. It also has four pre-punched holes for quick wall mounting and a mounting plate with a smooth surface for fixing your components inside the housing. The design and construction of the model series are characterized by high flexibility and adaptability to specific dimensions specified by the installation and/or desired by the end customer. The areas of application range from the feed and distribution to the conversion of electrical energy in industrial plants.
