Busch-Jaeger 2CKA006800A2119 Surface-mount Motion detector attachment Black
EAN:
Part number:
Item no:
Technical specifications
- Design: Presence detectors
- Material quality: Thermoplastic
- Surface protection: Untreated
- Design of surface: Matt
- KNX bus system: Yes
- KNX-RF bus system (radio): No.
- KNX Secure bus system: No.
- KNX Secure RF bus system (radio): No.
- Bus system wireless bus: No.
- Bus system LON: No.
- Bus system Powernet: No.
- Other bus systems: Without
- Mounting type: Surface-mounted
- With bus connection: Yes
- Transparent: No.
- Min Depth of the device socket 22 mm
- Wireless bidirectional: No
- Extension input: Yes
- Low-level creep protection: Yes
- Operating mode switch: No.
- Animal slope: No.
- Staircase lighting timer: Yes
- Response brightness adjustable: Yes
- Teach-Function for Response Brightness: Yes
- Switch-off delay, self-learning: No.
- Optimum mounting height 2 m.
- Max. Range to one side: 3 m.
- Max. Range: Front 20 m
- Mounting depth: 22 mm
- Min Switch-on time 10 seconds
- Max. duty cycle 1092 min
- Product type
Motion detector attachment
- Mounting type
Surface-mount
- Factory colour
Black
- Similar RAL
9005
- Width
49 mm
- Height
91 mm
- Dim
(W x H x D) 49 x 91 x 91 mm
- Channels
2
- Depth
91 mm
- Material
Plastic
- Recess depth
22 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3834484 Busch-Jaeger 2CKA006800A2119 Surface-mount Motion detector attachment Black
Description
For automatically switching consumers depending on motion and brightness. For sensing to the ground. For relay application 6401 U-102, 6402 U and 6812 U-101. For MOS-FET-use 6804 U-101. For dimmer use 6593 U. For extension use 6805 U. With integrated switch for OFF-AUTOMATIC-ON (lockable). Soft stop: In combination with the 6593 U (operating mode: Soft off), the lighting is dimmed and switched off within 60 seconds. Monitoring density: 28 sectors with 112 switching segments. Switch-off delay: Adjustable from 10 s to 30 min or short-time pulse of 1 s.
