Name: Camping First Satmex Dome Weiß SAT antenna
Brand: Camping First
SKU: 3804690
Availability: InStock

Map of Europe showing Astra satellite coverage footprint outlined in white over western and central Europe.

TV connected to a Camping First satellite dome by one coaxial cable only, with no separate power supply; German text says 'nur eine Koaxialleitung zum TV ohne separate Stromzufuhr'

Couple relaxing on chairs by a white camper van parked on a rocky riverbank under a clear blue sky.

Camping First Satmex dome satellite TV dome ad with German text, showing a white dome antenna and a motorhome by a river, promoting TV anywhere while camping or caravaning.

Camping First 'Satmex dome' satellite dome with automatic satellite search; highlights no manual adjustment, one-button alignment, and preset Astra 19.2°, shown on a motorhome camping scene.

Camping First Satmex dome setup ad showing three steps: set up antenna, connect cable, turn on TV; no separate power supply needed, receiver powers it; 'In wenigen Minuten einsatzbereit' headline.

Advertisement for 'Camping First' 'Satmex dome' portable satellite dome, with bullet points 'Platzsparend', 'Schnell verstaut', and 'Komfortabler Tragegriff', and a person loading it into a vehicle.

Satellite map of Europe showing the reception area for 'Astra 19,2° East' outlined in white.

Camping first Satmex dome with 43 cm height and 45 cm base, shown with included items: antenna connection cable 10 m and instruction manual.

1/10

Datasheet (PDF)

Fast track dispatch on Tue 27 Oct

4 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 539.00 / piece)

€ 539.00

incl. VAT

Only 4 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Camping First Satmex Dome - fully automatic satellite antenna for mobile use

Fully automatic SAT-reception: Aligns itself automatically to Astra 19.2° east
No extra power supply: Operation directly via receiver or TV
Robust & mobile: Weatherproof dome for camping and traveling
Flexible set-up: Optimal reception at clear sight
Compact & light: Approx. 450 × 430 × 450 mm, 4.2 kg including accessories

Technical specifications

Product type: SAT antenna

Documents & Downloads

Datasheet

Datasheet 3804690 Camping First Satmex Dome Weiß SAT antenna

User & Safety Instructions

User & Safety Instructions 3804690 Camping First Satmex Dome Weiß SAT antenna

Description

Camping First Satmex Dome
The Satmax Dome is a fully automatic satellite antenna that automatically aligns itself to Astra 19.2° east. Thanks to a robust plastic dome, it is Ideal for mobile use on the camp site or while traveling. The antenna does not need a separate power supply and is operated directly via the connected receiver or TV. Simple Plug-&-Play installation for quick TV reception while traveling.

Fully automatic satellite antenna for mobile TV reception
The Satmax Dome is a fully automatic satellite antenna with a robust plastic dome and was specially developed for mobile use. Whether camping, in caravans, traveling or in the garden – the antenna is quickly operational at all times and provides reliable TV reception, even with changing weather conditions.

Thanks to the fully automatic alignment, no manual adjustment is required. After switching on the antenna aligns itself automatically to Astra 19.2° east and thus provides for a stable satellite reception in a very short time. The compact, closed design protects the technology optimally against external influences and makes the Satmax Dome particularly easy to transport - Ideal for flexible outdoor adventure.

Simple power supply via receiver or TV
The Satmax Dome does not require a separate power supply. It is operated directly via the connected satellite receiver or a TV with integrated satellite tuner. A simple coaxial cable is sufficient to ensure both power supply and signal transmission.

After connecting the antenna starts the search for the satellite automatically and adjusts itself automatically to the desired satellite. Thus, the TV reception is possible quickly, easily and without additional accessories - Ideal for all, who are looking for a simple and reliable solution while on the move.

Technical data
Antenna type: Parabolic antenna
LNB type universal LNB
Maximum number of participants: 1
Frequency band: KU band
Input frequency range 10.7 GHz – 12.75 GHz
Polarisation: V/H
Signal amplification 31 dBi @ 12.7 GHz
Minimum EIRP (illumination zone): 51 DBW
Elevation (slope): 23° - 43°
Azimuth (rotation): 360°
1.5-axle DC motor
Temperature range -20° C – 70° C.
Mirror size 380 (Ø)

Satellites
Astra 1 (19.2° east)

Power Supply
Via TV/Receiver
