Name: Circuit breakers Black 3-pin 50 mm² 125 A 1 maker, 1 breaker 690 V AC Siemens 3LD28041TD51
Brand: Siemens
SKU: 1744377
Availability: BackOrder

A grey rotary switch with 'ON' and 'OFF' markings. The switch is set to 'OFF'. Several terminal blocks are visible in the background.

Wiring diagram of an electrical relay: A red 'X' marks a fault at terminal 1L. Contacts and terminals are numbered.

Technical drawing of a safety-critical switch with dimensional specifications in millimetres, showing front and side views along with mounting details.

1/3

Image similar

Product type

Circuit breakers

Nominal voltage

690 V AC

Number of pins

Nominal current - rounded value

125 A

Contact type

1 maker

1 breaker

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Fri 13 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 199.99 / piece)

€ 199.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

IP65 rating
Isolation voltage: 690 V
Operating frequency: 50/60 Hz
Ambient temperature: -25 °C to +55 °C
Surge voltage resistance: 6 kV
Mechanical life: 100000
Electrical life: 6000
Color of the actuator: black
Size of the switch disconnector: 4
Power loss: 48 W

Product type: Circuit breakers

Contact type: 1 maker
1 breaker

Operating voltage: 690 V AC

Nominal voltage: 690 V AC

Factory colour: Black

Cross section: 50 mm²

Number of pins: 3

Dim: (W x H x D) 90 x 106 x 112.5 mm

Nominal current: 125 A

Nominal current - rounded value: 125 A

Type: Step Switches

Width: 90 mm

Height: 106 mm

Depth: 112.5 mm

: 37 kW

: 1

: 1

: 125 A

: 3

: IP65

: 0

: 1

: TRUE

: FALSE

: Frame clamp

: FALSE

: Short thumb-grip

: TRUE

: TRUE

: TRUE

: 45 kW

: 2 kA

: Black

: FALSE

: TRUE

: FALSE

: FALSE

: FALSE

: 690 V

: FALSE

: FALSE

: Built-in device fixed built-in technique

: 125 A

: FALSE

: 80

: Other

UKCA: yes
