Name: Circuit breakers Red, Yellow 3-pin 185 mm² 250 A 690 V AC Siemens 3LD24180TK13
Brand: Siemens
SKU: 1744155
Availability: InStock

Rotary switch with a red lever and yellow background, designed for switching electrical devices on and off.

The diagram shows an electrical circuit diagram with contacts and connections. A contact labelled 'L' is crossed out in red.

Technical drawing of a mechanical shaft with various views and dimensioning, showing details and dimensions of the components.

1/3

Image similar

Product type

Circuit breakers

Nominal voltage

690 V AC

Number of pins

Nominal current - rounded value

250 A

Operating voltage

690 V AC

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 525.00 / piece)

€ 525.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

IP65 rating
Isolation voltage: 690 V
Operating frequency: 50/60 Hz
Ambient temperature: -25 °C to +55 °C
Surge voltage resistance: 8 kV
Mechanical life: 100000
Electrical life: 6000
Color of the actuator: red
Size of the switch disconnector: 5
Power loss: 108 W

Product type: Circuit breakers

Operating voltage: 690 V AC

Nominal voltage: 690 V AC

Factory colour: Red
Yellow

Cross section: 185 mm²

Number of pins: 3

Dim: (W x H x D) 112 x 169 x 94 mm

Nominal current: 250 A

Nominal current - rounded value: 250 A

Type: Emergency stop switch

Width: 112 mm

Height: 169 mm

Depth: 94 mm

: 110 kW

: 0

: 0

: 250 A

: 3

: IP65

: 0

: 1
