Name: Cordial 15589 RJ45 Patch cable CAT 7a S/FTP 1.50 m Black PUR coating 1 pc(s)
Brand: Cordial
SKU: 3344146
Availability: InStock

Two black XLR cables with labelling displaying technical details such as category and manufacturer information.

'CAT 6A U/FTP LAN Cable, black, with shielding and multi-coloured internal wires; for high-speed network connections.'

Diagram of an Ethernet cable with eight wires: orange-white, orange, green-white, blue, blue-white, green, brown-white, brown.

1/3

Product type

Patch cable

Specification

CAT 7a

Shielding

S/FTP

Connection type

RJ45

Cable length

1.50 m

Datasheet (PDF)

Fast track dispatch on Fri 23 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 43.99 / piece)

€ 43.99

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Assignment: RJ45 Pinout T568B
Neutrik ® / HIROSE ® connector brand
Wire cross-section (mm²): 0.14 mm²
AWG26/7
Conductor construction 7 x 0.14 mm²
Conductor insulations foam skin PE nom. 1.05 mm
Diameter outer sheath: 6.4mm +/- 0.2mm
Capacitance conductor (pF/m): Less than 44 pF/m
Conductor resistance (ohms / km): 140 Ω / km.
PoE (15.4W) IEEE 802.3af-2003 max. Channel PoE (15.4W) 70 m
Max. Channel link: Channel of Class FA / CAT 7A (@ 1000 MHz): 77m

Product type: Patch cable

: CAT 7a

: S/FTP

Connection type: RJ45

No. of A connectors: 1 x

Type A: RJ45 plug

No. of B connections: 1 x

Type B: RJ45 plug

Cable length: 1.50 m

Factory colour: Black

Connector version: straight

Cable features: PUR coating

Cable use: Networks

Version: Cable

Cable design: Round

Max. frequency: 1000 MHz

LAN transfer rate: 100 MBit/s
1000 MBit/s
2500 MBit/s
10000 MBit/s

Documents & Downloads

Datasheet

Datasheet 3344146 Cordial 15589 RJ45 Patch cable CAT 7a S/FTP 1.50 m Black PUR coating 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3344146 Cordial 15589 RJ45 Patch cable CAT 7a S/FTP 1.50 m Black PUR coating 1 pc(s)

Description

The data for the CSE NN 7A PUR patch cable consists of the CCAT 7A PUR by the meter as well as HIROSE® RJ45 plugs with Neutrik® etherCON® cable plug protection.
The CCAT 7A PUR network cable is the optimum choice for powerful networks. With its double shield S/FTP it can transfer signals of the data class CAT 7A with an impressive bandwidth of 1000 MHz (1 GHz, gigabit Ethernet). The robust PUR sheath protects the cable in mobile indoor and outdoor applications against environmental influences and mechanical load.
Designed specifically for audio networks, lighting control and EtherSound™ systems, it has a flexible inner conductor (AWG 26/7), WAS ES Ideal makes for patch cables and device connection cables. In addition, this cable supports Power over Ethernet (PoE) according to the standard IEEE 802.3af-2003 with a power of 15.4 watt, WAS significantly increases the flexibility in the application.
Its strong abrasion resistance as well as its resistance to oil, microbes and chemicals should also be highlighted. Whether for mobile applications, the stage mode or outdoor transmissions - this cable offers first-class performance and reliability, even under demanding conditions.
Flexible, robust, can be rolled,
PUR-sheath for mobile indoor/outdoor applications
Data class CAT 7A (1000 MHz)
Common shield S/FTP
AWG 26/7, with 7 wires/conductor
PoE (15.4W) IEEE 802.3af-2003 max. Channel PoE (15.4W) 70 m
Flame-resistant according to UL 1581 §1090, §1100 (FT2) and IEC 60332-1-2
Halogen-free as per EN 50267-2-1 and IEC 60754-1
Oil resistant according to IEC 60811-2-1, ICEA S-82-552 AND ASTM IRM 902
Mud resistance corresponds to NEK 606
Ozone resistance corresponds to EN 50396
Microbes-resistant as per VDE 0282/10
Chemical compatibility - good (diesel, kerosene, petroleum)
Neutrik® etherCON® cable plug protection + HIROSE® RJ45 plug
Transparent shrink hose for labeling the cables
Application: Data, Ethernet, audio networks, lighting control, EtherSound™
