Crimp contact 09060009554 HARTING Content: 1 pc(s) Crimp contact
Packaging type
Piece
Product type
Crimp contact
Type
09 06 000 9554
Manufacturer part #
09060009554
Connection
Crimp
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- DIN 41612 series
- Continuous resistance ≤ 20 mΩ
- Mating cycles ≥ 500
- Material contacts: Copper alloy
- Contact surface: Precious metal via Ni connector side; Ni connector side
- IEC 60603-2 standard supplement
- Net weight: 0.28 g
- Features: Lead-free
- Notes: Caution: Individual contacts are recommended for repair and maintenance only. For series production, we recommend the identical contacts on roll.
- Contact type: Crimp contact
- Contacts for: DIN 41612 design FM;DIN 41612 design 2F;DIN 41612 design F9
- Gender: Blade contact
- Manufacturing process: Punched contacts
- Conductor cross-section: AWG 24 ... AWG 28
- Stripping length: 3.5 ... 4 mm
- Wire outer diameter: 0.7 ... 1.5 mm
- Tensile strength: 11 ... 28 N
- Packaging type
Piece
- Type
09 06 000 9554
- Product type
Crimp contact
- Manufacturer part #
09060009554
- Connection
Crimp
- Content
1 pc(s)
- Material
Copper alloy
Pin
Other
Other
3.5 mm
0.09-0.25 mm²
0.09-0.25 mm²
Other copper alloys
500
Turned (lathe)
Documents & Downloads
Datasheet
Datasheet 3007615 Crimp contact 09060009554 HARTING Content: 1 pc(s) Crimp contact
User & Safety Instructions
User & Safety Instructions 3007615 Crimp contact 09060009554 HARTING Content: 1 pc(s) Crimp contact
Description
Crimp contact, blade contact, copper alloy, precious metal via Ni plug side, Ni connection side, conductor cross-section: 0.09...0.25 mm²
