Image similar
Degson Socket housing PCB Total number of pins 5 Contact spacing: 5.08 mm 2CDGB-5.08-05P-14-00A(H) 1 pc(s)
Product type
Socket housing PCB
No. of rows
1
CS
5.08 mm
Total number of pins
5
Pins per row
5
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Degson implementation base 5-pin
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 5
Our service for you
Technical specifications
- Product type
Socket housing PCB
- No. of rows
1
- CS
5.08 mm
- Pins per row
5
- Total number of pins
5
- Width
17.20 mm
- Nominal current
20 A
15 A
- Nominal current - rounded value
NaN A
- Content
1 pc(s)
- Dim
(L x W x H) 45.80 x 17.20 x 17.50 mm
- Connection
Print
- Case material
Polyamide 6.6
- Manufacturer part #
2CDGB-5.08-05P-14-00A(H)
- Factory colour
Green
- Contact material
Copper alloy, zinc plated
- Nominal voltage
320 V
300 V
- Height
17.50 mm
- Length
45.80 mm
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Type
2CDGB-5.08-05P-14-00A(H)
