DEHN 306105 PV 5.12.5 SKM8X45 GSG CUGALSN Fittings 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Fittings
- Manufacturer part #
306105
- Content
1 pc(s)
Galvanic tinned
Parallel connector
Hexagon screw
Copper
25 kA
5.0-12.5 mm
5.0-12.5 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2750455 DEHN 306105 PV 5.12.5 SKM8X45 GSG CUGALSN Fittings 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2750455 DEHN 306105 PV 5.12.5 SKM8X45 GSG CUGALSN Fittings 1 pc(s)
Information
Information 2750455 DEHN 306105 PV 5.12.5 SKM8X45 GSG CUGALSN Fittings 1 pc(s)
Description
Parallel connector for creating a potential equalization system in an explosive atmosphere. Spark-free tested for use in hazardous areas Ex-Zone 1 and 2 (gases of explosion group IIC) as well as Ex-Zone 21 and 22 (dust). Small design, for different cable diameters, with spring ring and two screws secured against self-loosening in accordance with DIN EN 62305-3 Appendix 2.
