Deko Light 565233 LED Panel Round III 20 LED recessed light EEC: G (A - G) LED (monochrome) Built-in LED 20 W Traffic wh
EAN:
Part number:
Item no:
Highlights & Details
LED ceiling mounted light fixture, LED Panel Round III 20, Ø 180 mm, 20W, 3000 K, aluminum, White
- Power= 20 W Total luminous flux= 1980 lm Colour temperature= 3000 K Warm white
Technical specifications
- Input voltage 28V/DC
- Input current 700 mA
- Colour reproduction Ra:80
- Light intensity 786 cd
- Durability: 30000 h
- Switching cycles: 15000
- Radiation distribution: 583 nm
- Number of LEDs:108
- LED type:SMD
- LED design: 2835
- Connectivity:open cable
- Power supplies: LED power supply
- Material 2: Plastic
- Optic 2:satined
- Product type
LED recessed light
- Operating voltage
28 V DC
- No. of bulbs
108
Built-in LED
- Bulb type
LED (monochrome)
- Rating per bulb
20 W
20 W
1980 lm
- Total luminous flux
1980 lm
3000 K
- Colour
Warm white
- Energy consumption
20 kWh/1000h
- Type
Circular
- Protection screen
Satinised
- Radiation angle
100°
- Recess depth
36 mm
- Outside Ø
160
IP20
- Protection class
III
- Factory colour
Traffic white (RAL 9016)
- Material
Aluminium (die-cast)
G (A - G)
- Dim
(Ø x H) 180 mm x 38 mm
- Light bulb included
Yes
- Colour temperature (min.)
3000 K
- Colour temperature range
3000 K (min)
- Height
38 mm
- (Ø)
180 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2795080 Deko Light 565233 LED Panel Round III 20 LED recessed light EEC: G (A - G) LED (monochrome) Built-in LED 20 W Traffic wh
Description
Scope of delivery
- 1x AMP plug with 20 cm cable, open ends
- This text is machine translated.
