Buy Digitus DN-91612S-EA-G 12 ports Network patch panel 254 mm (10") CAT 6A 1 U Multicolour Equipped

Patch panel with 12 Ethernet ports, numbered from 1 to 12, for network cabling; labelled 'CAT.6a'.

Network patch panel with twelve ports, open front, showing embedded electronics with red circuit boards.

A white patch panel with twelve numbered Ethernet ports, labelled as 'DIGITUS Professional CAT.6A'.

A white fibre optic module with numbered ports from 1 to 12, suitable for network cabling and telecommunications connections.

Close-up of a patch panel with multiple coloured Ethernet cable connections. The device is designed for network cabling.

Patch panel with multiple cable connections, numbered from 1 to 4. Colour-coded wires are connected to the contacts.

1/6

5 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 25.20 / piece)

€

Only 5 Piece(s) available

Report legal concerns

Highlights & Details

Digitus CAT 6A patch panel, 10", 12-port, shielded, 1HE, rack mount, gray

Robust patch panel with sturdy metal housing
Complete shielding of housing and shield contact
Cable installation via LSA-strips
Central grounding connection
Dielectric strength up to 1500 VDC (contact / ground)

Technical specifications

Transfer property: Category 6A, class EA
Application areas: Up to 500 MHz, 10GBase-T.
Standards: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C, 802.3af, 802.3at PoE+
Suitable for 10" (254 mm) cabinet mounting
RJ45 sockets, 12P12C
Cable installation via LSA-strips, color-coded according to EIA/TIA 568 A & B.
Cable fixing by means of cable ties
Central grounding connection
360° shield contact
Material casing: 1.5 mm galvanized, cold-rolled steel according to EN 1.4301, US S30400, AISI 304 and LMSAD110
Material RJ45 socket: ABS UL 94V-0
Contact RJ45 socket: Nickel plated phosphor bronze, 0.5 μ gold plated contact
RJ-45 shielding: Nickel-plated bronze
LSA-cutting terminal: Krone LSA+, UL 94V-0, galvanized phosphor bronze
Grounding wire: Not included
PRINTED CIRCUIT BOARD FR4, UL 94V-0
Insertion force: 30N max. (IEC 60603-7-5)
Tensile load: 7.7 kg between socket and plug
OPERATING TEMPERATURE -20° C TO +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
Plug-in cycle socket: Greater than 750 in accordance with ISO/IEC 11801, IEC 60603-7-5
Terminal: Greater than 200 in accordance with ISO/IEC 11801, IEC 60603-7-5
Insulation resistance: Greater than 500 MOhm
Contact resistance: Less than 20 milliohms
Dielectric strength 1000VDC (contact/contact), 1500VDC (contact/ground)
Colour: grey.
Category: Cat.6A
Connections: 12
Wire intake: 22-26 AWG solid and stranded conductor

Product type: Network patch panel

Rack size: 254 mm (10")

: CAT 6A

Rack unit: 1 U

Transfer rate: 10 GBit/s

Port: 12 ports

Patch panel design: Equipped

Connection method: LSA+

Connections: RJ45

Width: 110 mm

Height: 44 mm

Factory colour: Multicolour

Length: 255 mm

Weight: 0.89

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2143954 Digitus DN-91612S-EA-G 12 ports Network patch panel 254 mm (10") CAT 6A 1 U Multicolour Equipped

Description

Future-oriented standards and high-end quality for your network
The DIGITUS® CAT 6A patch panel is available in the 12-port version and with its 1.5 mm galvanized cold-rolled steel, it is a robust patch panel for 10" cabinet mounting. It corresponds to the (IEEE 802.3at/af) PoE+ standard. The patch panel is electromagnetically shielded and thus offers loss-free and interference-free transmission of the data of your network infrastructure. The 360° shielding at the contact points ensures that every single consolidation point is also cleanly shielded.

This text is machine translated.

Features

Transfer property: Category 6A, class EA
Application areas: Up to 500 MHz, 10GBase-T.
Standards: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C, 802.3af, 802.3at PoE+
Suitable for 10" (254 mm) cabinet mounting
RJ45 sockets, 12P12C
Cable installation via LSA-strips, color-coded according to EIA/TIA 568 A & B.
Cable fixing by means of cable ties
Central grounding connection
360° shield contact
Material casing: 1.5 mm galvanized, cold-rolled steel according to EN 1.4301, US S30400, AISI 304 and LMSAD110
Material RJ45 socket: ABS UL 94V-0
Contact RJ45 socket: Nickel plated phosphor bronze, 0.5 μ gold plated contact
RJ-45 shielding: Nickel-plated bronze
LSA-cutting terminal: Krone LSA+, UL 94V-0, galvanized phosphor bronze
PRINTED CIRCUIT BOARD FR4, UL 94V-0
Insertion force: 30N max. (IEC 60603-7-5)
Tensile load: 7.7 kg between socket and plug
OPERATING TEMPERATURE -20° C TO +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
Plug-in cycle socket:> 750 acc. To ISO/IEC 11801, IEC 60603-7-5
Terminal 200> acc. To ISO/IEC 11801, IEC 60603-7-5
Wire intake: 22-26 AWG solid and stranded conductor
Insulation resistance> 500 MOhm
Contact resistance< 20 milliohms
Dielectric strength 1000VDC (contact/contact), 1500VDC (contact/ground)
