EA Elektro Automatik EA-EL 9200-210 B Electrical load 200 V DC 210 A 6000 W

These conventional controllable and programmable electronic loads in 19" 3 U design, with a powerful micro-controller (FPGA) with 16 bit resolution. The DC input area is extremely flexible and allows the use at high input voltages or, alternatively, high input current in the framework of the respective nominal power. For a comfortable use, this series have a high-resolution, intuitive TFT touch panel with built-in function generator and pre-defined curve forms (e.g. Sine, trapezoidal, square, ramp, arbitrary) as well as alarm manager, memory and memory user profiles. The display resolution is 4 dig. In the range from 0 to 100% adjustable DC input parameters (U, I, P, R) have a high accuracy and stability, are very dynamic (current pulse of up to 50 µs) and free of ripple (FET-linear amplifier). For the remote-controlled operation, the devices as a standard isolated analog interface (0 - 5 V/0-10V) as well as via USB. On the back of the plug'n play slot can be further interface options such as CANopen, Ethernet, Profibus/net, RS232 or Modbus can be upgraded. This device series is an indispensable tool for the reproducibility of test results and is suitable for integration in professional automated test benches and to cascade for high load applications.

This text is machine translated.
