Name: Joy-it JT-HD35 Electrical load 5 A 35 W
Brand: Joy-it
SKU: 1874704
Availability: InStock

An electronic circuit board with a small fan, USB port and digital display showing '1.589'.

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

107 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 20.99 / piece)

€ 20.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

JT-HD 35 USB load resistor 35 watts.

USB-load resistance up to 35 W
Adjustable via built-trimmer
LCD display of current current
Buttons for switching on/off of the load
Simulation of different charging electronics: QC2.0 (5 V, 9 V, 20 V), QC3.0, FCP, AFC 9 V
Connections: USB 2.0, Micro USB, USB Type C

Technical specifications

Operating voltage 4 to 25 V DC
Operating current: 0.25 to 5 A
4 digits segment indicator (red)
Fan speed is temperature-controlled
Connections: USB 2.0, Micro USB, USB Type C

Type: JT-HD35

Product type: Electrical load

Min. input voltage: 4

Input voltage (max.): 25

Load input current (max.): 5 A

Max. non-stop power rating: 35 W

Dim: (L x W x H) 400 cm x 41 mm x 28 mm

Weight: 52

: Manufacturer's standards (no certificate)

Inputs: A

Width: 41 mm

Height: 28 mm

Depth: 84 mm

Length: 400 cm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1874704 Joy-it JT-HD35 Electrical load 5 A 35 W

User & Safety Instructions

User & Safety Instructions 1874704 Joy-it JT-HD35 Electrical load 5 A 35 W

Description

With the JT HD 35 you get a compact, electronic USB-load resistor with an efficiency of up to 35 Watt. The current current can be easily via the LCD display can be read. In addition, the device has an adjustable trimmer and is capable of different charging electronics, such as QC2.0, QC 3., FCP and AFC 9 V, to simulate. With a maximum voltage of 25 V and a maximum current of 5 A, it is suitable for almost every application. The built-in heat sink provides, in conjunction with the temperature-controlled fan unit, for effective cooling of the entire device. With the help of the integrated button you can activate or deactivate the configured load also quickly and easily.
