Enda ETM2432-230 TDR Multifunction 230 V AC 1 pc(s) Time range: 0.01 - 99.59 min 2 change-overs

EAN:
Part number:
Item no:
Digital timer with red LED display, showing '28:00'. Includes 'Start,' 'Set,' and 'Stop' buttons, model ETM2432 by ENDA.
Product type
TDR
Type
Multifunction
Functions
Selectable delay
Operating voltage
230 V AC
Min. operating voltage
184 V AC
Datasheet (PDF)
Fast track dispatch on Tue 27 Oct
11 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 81.99 / piece)
€ 81.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Enda ETM2432-230 digital time relay

  • Double-contact output for time control
  • External start, reset and gate input
  • Selection between hour, minute and minute seconds displays
  • Scale 0:01...99:59 minutes, 0:01...99:59 hours
  • The time increase and reduction steps can be adjusted as required.
  • Countdown
  • Start and stop facility on front plate
  • 8 different warning sound choices
  • Lower and upper limits of the setpoint can be adjusted.
  • CE-labeled according to EN standards

Technical specifications

  • Power consumption: Max. 7VA.
  • Display: 4 digits, 12.5mm, 7 segment red LED.
  • Electrical safety EN 61010-1:2010 (pollution level 2, protection class II). Electromagnetic compatibility EN 61326-1:2013.
Product type

TDR

Type

ETM2432-230

Type

Multifunction

Connection

Screw terminal

Functions

Selectable delay

Operating voltage

230 V AC

Min. operating voltage

184 V AC

Max. operating voltage

253 V AC

Operating voltage

184 - 253 V AC

Contact type

2 change-overs

Switching voltage (max.)

250 V AC

Switching current (max.)

8 A

Time range (min.)

0.01 min

Time range (max.)

99.59 min

Time range(s)

99 min 59 s (value.1402950)

Min. temperature

0 °C

Max. temperature

50 °C

IP65 (front)

IP20 (back panel)

Electrical lifespan

300,000 switching cycles at 250V AC, 2A

Durability

30 MIO. Switching cycles (without load)

Width

35 mm

Height

77 mm

Depth

71 mm

Dim

(W x H x D) 35 x 77 x 71 mm

Industrial packaging

Yes

Content

1 pc(s)

Documents & Downloads

Datasheet

Datasheet 3527754 Enda ETM2432-230 TDR Multifunction 230 V AC 1 pc(s) Time range: 0.01 - 99.59 min 2 change-overs

User & Safety Instructions

User & Safety Instructions 3527754 Enda ETM2432-230 TDR Multifunction 230 V AC 1 pc(s) Time range: 0.01 - 99.59 min 2 change-overs

Description

The Enda ETM2432 is a versatile, programmable digital timer relay for panel installation (DIN 43700, 77 × 35 mm). It possesses two relay outputs as changeover contacts (NO/NC), external control inputs (start, reset, gate) and a freely programmable time function (selectable from 0:01 to 99:59 min or h).
