ESYLUX EO10298929 ELSA-2 DL#EO10298929 LED recessed light LED (monochrome) Built-in LED 9 W White
EAN:
Part number:
Item no:
Highlights & Details
ESYLUX LED DOWNLIGHT 3000K DALI ELSA-2 DL#EO10298929
- Power= 9 W Total luminous flux= 850 lm Colour temperature= 3000 K White
Technical specifications
- Connection type: crimping
- Rated life L70/B10 at 25 °C: 60000 h.
- Rated life L70/B50 at 25 °C: 60000 h.
- Rated life L80/B10 at 25 °C: 40000 h.
- Rated life L80/B50 at 25 °C: 40000 h.
- Rated life L90/B10 at 25 °C: 20000 h.
- Rated life L90/B50 at 25 °C: 20000 h.
- Rated luminous flux according to IEC 62722-2-1: 850 lm
- Rated ambient temperature according to IEC62722-2-1: -20..40 °C.
- Operating device: LED operating device current-controlled
- Screen workstation suitable according to EN 12464-1: no.
- Dimming depends on the operating device: Yes
- Dimming DALI: Yes
- With bulb: Yes
- Colour temperature: 3000 K
- Color rendering index CRI: 80-89
- Suitable for installation: no.
- Suitable for ceiling mounting: Yes
- Suitable for panel mounting: Yes
- Suitable for wall mounting: no.
- Power factor: 1
- Conductor cross-section: 1 mm²
- Light output 94 lm/W
- Lamp: LED not replaceable
- Light emission: Direct
- Light splitter: Diffuser lens/optics/panel
- Light distribution: Symmetrical
- With operating device: Yes
- With bulb: Yes
- Surface: Powder-coated
- Reflector: White
- Voltage type: AC
- Material of the cover: Plastic opal
- Product type
LED recessed light
- Operating voltage
240 V
- No. of bulbs
1
Built-in LED
- Bulb type
LED (monochrome)
- Rating per bulb
9 W
9 W
850 lm
- Total luminous flux
850 lm
3000 K
- Colour
White
- Radiation angle
80°
- Light features
Dimmable
- Recess diameter
165 mm
- Recess depth
50 mm
- Outside Ø
180 mm
IP20
- Protection class
II
- Factory colour
White
- Material
Aluminium
n.rel.
Yes
- Light bulb included
Yes
- Colour temperature range
3000 K
- Height
25 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2297044 ESYLUX EO10298929 ELSA-2 DL#EO10298929 LED recessed light LED (monochrome) Built-in LED 9 W White
Description
LED Downlight, 9 W for ceiling installation. Recessed light with opal cover (diffuser). High-quality housing, light body made of aluminum, white powder-coated (RAL 9003). Can be used as a ceiling installation without any additional accessories. Color temperature: 3000 K with lowest color tolerances. Luminous flux 850 lm. Good light quality. Very good system efficiency. Rated life L80B50 at 25 °C: 40000 h. Operating device: DALI SwitchDIM (already included).
This text is machine translated.
This text is machine translated.
What kind of Flush Mount Lighting are you looking for?
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
