Image similar
ESYLUX EO10298950 ELSA-2 DL#EO10298950 LED recessed light LED (monochrome) Bulb cannot be changed 18 W White
EAN:
Part number:
Item no:
Highlights & Details
ESYLUX LED DOWNLIGHT 4000K DALI ELSA-2 DL#EO10298950
- Power= 18 W Total luminous flux= 1750 lm Colour temperature= 4000 K White
Technical specifications
- Connection type: crimping
- Rated luminous flux according to IEC 62722-2-1: 1750 lm
- Rated ambient temperature according to IEC62722-2-1: -20..40 °C.
- Operating device: LED operating device current-controlled
- Screen workstation suitable according to EN 12464-1: no.
- Dimming depends on the operating device: Yes
- Dimming DALI: Yes
- Color consistency (McAdam ellipse): SDCM3
- Colour temperature: 4000 K
- Color rendering index CRI: 80-89
- Suitable for installation: no.
- Suitable for ceiling mounting: Yes
- Suitable for panel mounting: Yes
- Suitable for clamp mounting: no.
- Suitable for busbar mounting: no.
- Power factor: 1
- Conductor cross-section: 1 mm²
- Light output 100 lm/W
- Lamp: LED not replaceable
- Light emission: Direct
- Light splitter: Diffuser lens/optics/panel
- Light distribution: Symmetrical
- With operating device: Yes
- With bulb: Yes
- Surface: Powder-coated
- Reflector: White
- Voltage type: AC
- Material of the cover: Plastic opal
- Product type
LED recessed light
- Operating voltage
240 V
- No. of bulbs
1
Bulb cannot be changed
- Bulb type
LED (monochrome)
- Rating per bulb
18 W
18 W
1750 lm
- Total luminous flux
1750 lm
4000 K
- Colour
White
- Radiation angle
80°
- Light features
Dimmable
- Recess diameter
225 mm
- Recess depth
50 mm
- Outside Ø
240 mm
IP20
- Protection class
II
- Factory colour
White
- Material
Aluminium
n.rel.
Yes
- Light bulb included
Yes
- Colour temperature range
4000 K
- Height
25 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2292495 ESYLUX EO10298950 ELSA-2 DL#EO10298950 LED recessed light LED (monochrome) Bulb cannot be changed 18 W White
Description
LED Downlight, 18 W for ceiling installation. Recessed light with opal cover (diffuser). High-quality housing, light body made of aluminum, white powder-coated (RAL 9003). Can be used as a ceiling installation without any additional accessories. Color temperature: 4000 K with lowest color tolerances. Luminous flux: 1750 lm. Good light quality. Very good system efficiency. Rated life L80B50 at 25 °C: 40000 h. Operating device: DALI SwitchDIM (already included).
This text is machine translated.
This text is machine translated.
What kind of Flush Mount Lighting are you looking for?
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
