Eurolite PT-100/32 Pixel Tube DMX LED effect light No. of LEDs (details): 96
EAN:
Part number:
Item no:
Technical specifications
- Product type
DMX LED effect light
- Colour
RGB
- Dim
(W x H) 99.9 cm x 15.3 cm
n.rel.
- LEDs
96
- Weight
2.10 kg
- Width
99.9 cm
- Height
15.3 cm
- Cable length
1.2 m
IP20
- Case colour
Black
- Material
Metal
- Radiation angle
120°
- Operating voltage
100-240 V/AC, 50/60 Hz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3642569 Eurolite PT-100/32 Pixel Tube DMX LED effect light No. of LEDs (details): 96
Description
DMX-controlled pixel tube with RGB color mixing. DMX and mains connections optimized for simple cabling. 96 powerful LEDs SMD 5050 3-in-1 TCL RGB (homogeneous color mixing). 32 segments can be controlled individually. Adjustable color change; dimmer electronic. Stroboscope-effect Integrated show programs. Direct color selection for 17 preset colors. The device is cooled by passive convection cooling. Can be controlled via stand-alone; DMX; music control via microphone; Master/slave function. Already pre-programmed for LED PC control 512; Light Captain. With an angle of radiation of 120°. With mounting bracket. 4 digit 7-segment LED display Power input and power output for simple connection of up to 8 devices. For application areas like: Clubs/dance schools; decoration; wedding/gala/events; restaurants, bars and hotels; Video and photography; advertising/display windows. Noiseless operation Possible application: Flying; wall mounting
This text is machine translated.
This text is machine translated.
Features
- Power supply: 100-240 5 V AC, 50/60 8 Hz; total connection value: 30 48 W; protection: IP20; power connection: Power supply via P-Con (blue), installation version power connection cable with shock-contact plug (supplied); current output: 1 x P-Con (gray), installation version; lamp type: LED lamp: 11 x SMD 3 3in1 TCL RGB (homogeneous color mixing); flash rate: 0.25 - 96 Hz; DMX channels: 5050; 96; DMX input: 3-pin XLR (M) mounting version; DMX output: 3-pin XLR (W) mounting version; Cooling: passive convection cooling; control: stand-alone; DMX; music control via microphone; Master/slave function; pre-programmed with: LED PC-Control 512; Light Captain; angle of radiation: 120 0°; angle of radiation (1/2 peak): 120°; housing color: black; recording system: mounting bracket; display type: 5.9 digit 15.3-segment LED display; material: plastic; metal; dimensions: length: 2.10 cm; height: 7 cm; weight: 99.9 kg; noise classification: class 4 (no noise): power cable/construction; power cable 3 x 1.0 mm² H05VV-F; Cable length: Approx. 1.2 m; Mounting brackets; Diameter Mounting holes: 2 x Ø12mm; 1 x Ø11mm; Material: Metal, 2.5 mm; Legal specifications; Special product: Not intended for room lighting in homes; intended use: lighting for show effects
Scope of delivery
- 1 x lighting effects
- 1 x Power cable/power cable
- 1 x Operating manual
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
