Image similar
FESTO Bleed valve 2280 SE-3/4 0.5 up to 10 bar 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 209.99 / piece)
€ 209.99
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
SE-3/4
Technical specifications
- Operating medium
According to ISO 8573-1:2010 compressed air [7:4:4]
- Product type
Bleed valve
- Min. display range
0.5 bar
- Display range (max.)
10 bar
- Operating temperature
-20 up to +75 °C
- Min. operating temperature
-20 °C
- Max. operating temperature
+75 °C
- Manufacturer part #
2280
- Connection
G3/4
- Max. operating pressure
10 bar
- Operating pressure (min.)
0.5 bar
- Pressure range
0.5 up to 10 bar
- Operating medium
Compressed air
- Width
19 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2115138 FESTO Bleed valve 2280 SE-3/4 0.5 up to 10 bar 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2115138 FESTO Bleed valve 2280 SE-3/4 0.5 up to 10 bar 1 pc(s)
Information
Information 2115138 FESTO Bleed valve 2280 SE-3/4 0.5 up to 10 bar 1 pc(s)
Description
Rapid venting valve SE-3/4 valve function = rapid venting, pneumatic connection 1 = G3/4, pneumatic connection 2 = G3/4, mounting type = With Through Hole, normal rated flow ventilation = 7500 l/min
