Image similar
FESTO Oil lubricator MS9-LOE-G-U 564144 Enclosure material Aluminium (die-cast)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 234.99 / piece)
€ 234.99
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
MS9-LOE-G-U
Technical specifications
- Size: 9
- Mounting type: cable installation, with accessories
- Operating medium
Air quality class 5:7: - in accordance with DIN ISO 8573-1
- Type
564144
- Product type
Oil lubricator
- Enclosure material
Aluminium (die-cast)
- Max. operating pressure
16 bar
- Manufacturer part #
564144
- Operating pressure (min.)
1 bar
- Weight
2000 g
- Material
Aluminium (die-cast)
- Media temperature (range)
-10 up to +60 °C
- Max. media temperature
+60 °C
- Media temperature (min.)
-10 °C
- Max. ambient temperature
+60 °C
- Min. ambient temperature
-10 °C
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2121179 FESTO Oil lubricator MS9-LOE-G-U 564144 Enclosure material Aluminium (die-cast)
User & Safety Instructions
User & Safety Instructions 2121179 FESTO Oil lubricator MS9-LOE-G-U 564144 Enclosure material Aluminium (die-cast)
Description
Oiler MS9-LOE-G-U metal bowl, flow direction from left to right. Size=9, series = MS, mounting position = vertically +/-5°, constructive design = proportional standard oil mist oiler, max. Oil capacity = 490 ml
This text is machine translated.
This text is machine translated.
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
