Fränkische Rohrwerke 22630020 Pipe 3 m Grey 3 m
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Material: PVC, UV-stabilized
- Halogen-free: No.
- Flame-resistant version: Yes
- Bending behavior: Rigid
- With sleeve: Yes
- Compressive strength: Heavy (class 4)
- Impact resistance: Medium (class 3)
- Flush mounting: Yes
- Surface mounting: Yes
- Suitable for installation on wood: Yes
- Suitable for hollow wall installation: Yes
- Suitable for concrete installation: Yes
- Machinery and equipment installation: Yes
- Underfloor installation (screed): Yes
- Outdoor installation: Yes
- Suitable for laying in the ground: Yes
- Interior diameter 16.6 mm
- Outer diameter: 20 mm
- Operating temperature 25 °C .60 °C
- High-gloss smooth inner layer: No.
- Colour: grey
- RAL number: 7035
- Product type
Pipe
- Outside Ø
20 mm
- Inside diameter
16.6 mm
- Length
3 m
- Content
3 m
- Material
PVC
- Compressive strength
1250 N
- Factory colour
Grey
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3407387 Fränkische Rohrwerke 22630020 Pipe 3 m Grey 3 m
User & Safety Instructions
User & Safety Instructions 3407387 Fränkische Rohrwerke 22630020 Pipe 3 m Grey 3 m
Description
FPKu-ES-F-UV gray is a heavy plastic pole tube made of modified PVC, in gray color (RAL 7035), non-flame retardant, UV-stabilized, in bars to 3M, with sleeve shaped on one side. This plastic tube is used for surface mounting in the open and in industrial plants. The advantages are its heavy compressive strength and corrosion resistance against acids and bases. UV-stable up to 10 years. VDE 0605 DIN EN 61386-21 Minimum pressure resistance 1250N / 5cm
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1 x 3 m tube
