HARTING 09 69 400 0077 09694000077 Connector Number of pins: 7 Socket 1 pc(s)
Product type
Connector
Connector type
Socket, straight
Number of pins
7
Connection
Socket
Content
1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Connectors
- Connector
- Number of pins: 7
Technical specifications
- Series D-Sub
- Component: Connector
- Contact description: Straight
- Number of contacts: 7
- Locking type: Flange with passage hole Ø 3.1 mm
- Insulation resistance > 5 x 109 Ω
- Temperature limit: -55 ... +125 °C
- Mating cycles ≥ 500
- Test voltage Ueff 1 kV
- Insulation material group IIIa (175 ≤ CTI < 400)
- Material Application: Thermoplastic molding material, glass fiber reinforced (polyester);Shell: Steel, tin plated
- Colour insert: Black
- Material flammability class acc. To UL 94: V-0
- Net weight: 10.182 g
- Designation: Mixed
- Number of signal pins: 0
- Notes: Order special contacts separately.
- Number of special contacts: 7
- Hot plugging: No.
- Gender: Jack
- Size D-Sub 4
- Type
D-Sub
- Product type
Connector
- Connector type
Socket, straight
- Number of pins
7
- Connection
Socket
- Content
1 pc(s)
- Mating cycles
≥ 500
- Manufacturer part #
09694000077
- Factory colour
Black
- Features
+ sleeve
- Type
09 69 400 0077
Plug/bus
7
Documents & Downloads
Datasheet
Datasheet 3003933 HARTING 09 69 400 0077 09694000077 Connector Number of pins: 7 Socket 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3003933 HARTING 09 69 400 0077 09694000077 Connector Number of pins: 7 Socket 1 pc(s)
Description
Connector, socket, size: D-Sub 4, thermoplastic molded, glass fiber reinforced (polyester), Shell: steel, tin-plated, green, contacts: 7
