HARTING 09751206974 Edge connector (pins) No. of rows 2 1 pc(s)
Product type
Edge connector (pins)
Connector type
straight
CS
2.54 mm
Content
1 pc(s)
Total number of pins
20
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
- Total number of pins 20
- No. of rows 2
- Content 1 pc(s)
Technical specifications
- Product type
Edge connector (pins)
- Connector type
straight
- Total number of pins
20
- No. of rows
2
- CS
2.54 mm
- Connection
Press-in
- Factory colour
Pebble grey (RAL 7032)
- Case material
PA
- Manufacturer part #
09751206974
- Content
1 pc(s)
- Contact material
Copper alloy
- Type
09 75 120 6974
Other
20
Other
-40-105 °C
Other
Press-in connection
Other
13 mm
2.54 mm
2
1.6 mm
2.54 mm
Thermoplastic
90° (upwards vertical)
Flange
2 A
