HARTING 14010413102333 Print terminal 0.75 mm² Number of pins 4 Black 1 pc(s)
Product type
Print terminal
CS
2.54 mm
Number of pins
4
Connection
Push-in spring-loaded terminal
Type
14 01 041 3102 333
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Range: Har-flexicon®
- Component: Print terminal
- Connection type: Push-in spring-force connection;reflow soldering connection (SMT)
- Type of connection: Circuit board to cable
- Number of contacts: 4
- Plug contact series 1
- Pitch, connection side 2.54 mm
- Rated current 6 A
- Insulation resistance >109 Ω
- Continuous resistance ≤ 20 mΩ
- Temperature limit: -40 ... +125 °C
- Insulation material group IIIa (175 ≤ CTI < 400)
- Material application: Liquid-crystal polymer (LCP)
- Colour insert: Black
- Material contacts: Copper alloy
- Contact surface: Sn over Ni connectors side; Sn over Ni connection side
- Material flammability class acc. To UL 94: V-0
- Net weight: 2.5 g
- Airway: 1.5 mm
- Creepage distance 1.6 mm
- Features: Re-connection: 10 times (only for the same or larger cross-section)
- Rated voltage: 160 V
- Dimensioning surge voltage: 2.5 kV
- Pollution level 3
- Notes: Conductor cross-sections (rigid/flexible) up to 0.75 mm² possible, with a rated voltage of 32 V at III/2.
- Plug-in force ≤ 20 N
- Pull force ≥ 4 N
- Conductor cross-section: AWG 26 ... AWG 20
- Stripped length: 6 mm
- Description: Horizontal
- Vibration resistance 5-150 Hz, 5 g, 0.35 mm, 2h/axis
- Type
14 01 041 3102 333
- Product type
Print terminal
- Features
+ push-in spring bracket
- CS
2.54 mm
- No. of rows
1
- Number of pins
4
- Min. stripping length
6 mm
- Stripping length (max.)
6 mm
- Connection
Push-in spring-loaded terminal
- Nominal current
6 A
- Nominal current - rounded value
6 A
- Cross section (flexible) (max.)
0.75 mm²
- Cross section (inflexible) (max.)
0.75 mm²
- AWG (min.)
26
- AWG max.
20
- Contact material
Copper alloy
- Enclosure material
Copper alloy
- Factory colour
Black
- Weight
2.5 g
- Manufacturer part #
14010413102333
- Content
1 pc(s)
- Nominal voltage
160 V
Printed circuit board to cable
Other
160 V
4
Other
-40-125 °C
Other
2.5 kV
Soldering connection
Tin
2.54 mm
1
Liquid crystal polymer
Other
Other
6 A
Documents & Downloads
Datasheet
Datasheet 3003614 HARTING 14010413102333 Print terminal 0.75 mm² Number of pins 4 Black 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3003614 HARTING 14010413102333 Print terminal 0.75 mm² Number of pins 4 Black 1 pc(s)
Description
PCB terminal, horizontal, push-in spring force connection, rated current 6 A, contacts: 4, copper alloy
