HARTING 15210822601000 Edge connector (sockets) No. of rows 2 280 pc(s)
Product type
Edge connector (sockets)
Connector type
straight
CS
1.27 mm
Content
280 pc(s)
Total number of pins
82
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
- Total number of pins 82
- No. of rows 2
- Content 280 pc(s)
Technical specifications
- Product type
Edge connector (sockets)
- Connector type
straight
- Total number of pins
82
- No. of rows
2
- CS
1.27 mm
- Connection
SMT
- Case material
PA
- Manufacturer part #
15210822601000
- Content
280 pc(s)
- Contact material
Copper alloy
- Type
15 21 082 2601 000
Other
82
Other
-55-125 °C
Other
Soldering connection
Tin
1.27 mm
2
1.27 mm
Liquid crystal polymer
90° (upwards vertical)
Other
